Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber
Suspension Fork
Cervélo All-Carbon, Tapered R5 Fork for Disc
Drivetrain
Rear Derailleur
Shimano Dura-Ace Di2 9150, 11 speed
Front Derailleur
Shimano Dura-Ace Di2 9150, 11 speed
Shift Levers
Shimano Dura-Ace Di2 9170, 11 speed
Cassette
Shimano Dura-Ace CS-R9100, 11-28
Crank
Shimano Dura-Ace 9100 52/36
Bottom Bracket
BBB Bottomfit BBO-72, PF30 Threaded
Chain
Shimano CN-HG901, 11 speed
Wheels
Rims
ENVE SES 3.4 Disc
Tires
Continental Grand Prix 700 x 25c
Brakes
Brakes
Shimano Dura-Ace 9170 Hydraulic Disc
Cockpit
Stem
Cervélo Carbon Stem
Handlebar
Cervélo, AB06
Headset
FSA IS2 1-1/8 x 1-1/2
Seat
Saddle
fi’zi:k Antares R5
Seatpost
Cervélo Carbon SP18
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.378 mm | 1.412 mm | 1.442 mm | 1.47 mm | 1.494 mm | 1.52 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 264 mm | 264 mm | 266 mm | 266 mm |
| Front Center | 573 mm | 576 mm | 577 mm | 594 mm | 611 mm | 627 mm |
| Rake | 57 mm | 51 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 57 mm | 57 mm | 57 mm | 57 mm | 57 mm | 57 mm |
| Stack | 499 mm | 524 mm | 548 mm | 572 mm | 596 mm | 620 mm |
| Reach | 362 mm | 371 mm | 380 mm | 389 mm | 399 mm | 408 mm |
| Top Tube Length | 516 mm | 532 mm | 548 mm | 564 mm | 581 mm | 598 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 83 mm | 103 mm | 125 mm | 151 mm | 178 mm | 203 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 972 mm | 974 mm | 976 mm | 993 mm | 1011 mm | 1027 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 72 mm | 72 mm | 69 mm | 69 mm |
| Standover Height | 693 mm | 723 mm | 753 mm | 784 mm | 815 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
R5d Dura Ace DI2 9170 is a Cervelo R5d model. Cervélo released 3 bikes variations of this model so far. Take a sneak peek at all Cervelo R5d bikes models from 2018, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Race bikes average price
Our math shows that the average cost of a dependable Race bike is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
As for the wheels, Cervélo R5d Dura Ace DI2 9170 2018, has a 700c carbon model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The R5d Dura Ace DI2 9170 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
