Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber
Suspension Fork
Cervélo All-Carbon, Tapered S5 Fork
Drivetrain
Rear Derailleur
SRAM Force eTap AXS 12 spd
Front Derailleur
SRAM Force eTap AXS 12 spd
Shift Levers
SRAM Force eTap AXS HRD 12 spd
Cassette
SRAM Force 12s XG1270, 10-28
Crank
SRAM Force AXS 48/35 with Power Meter
Bottom Bracket
Ceramic Speed Dub
Chain
SRAM Force, 12 spd
Wheels
Rims
Reserve 50mm DT350 XDR, 24h (F), 24h (R), 21mm IW, Center-Lock, Tubeless Ready OR Reserve 50mm Zipp 76/176 XDR, 24h (F), 24h (R), 21mm IW, Center-Lock, Tubeless Ready
Tires
Vittoria Corsa TLR G2.0 25c
Brakes
Brakes
hydraulicDisc
Cockpit
Stem
Cervélo CS028 Carbon V-Stem
Handlebar
Cervélo AB08 Carbon
Headset
FSA IS2 1 x 1-3/8
Seat
Saddle
Prologo Dimension NACK OR Selle Italia NOVUS BOOST EVO Superflow Carbon
Seatpost
Cervelo Carbon SP20 Seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.39 mm | 1.42 mm | 1.45 mm | 1.47 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 266 mm | 266 mm | 268 mm |
| Front Center | 579 mm | 580 mm | 581 mm | 588 mm | 604 mm |
| Rake | 58 mm | 52 mm | 46 mm | 43 mm | 43 mm |
| Trail | 57.1 mm | 57 mm | 57.1 mm | 57 mm | 57 mm |
| Stack | 491 mm | 514 mm | 537 mm | 560 mm | 583 mm |
| Reach | 362 mm | 371 mm | 379 mm | 387 mm | 396 mm |
| Top Tube Length | 515 mm | 530 mm | 545 mm | 560 mm | 576 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 510 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 69 mm | 87 mm | 109 mm | 130 mm | 157 mm |
| Chainstay Length | 400 mm | 400 mm | 400 mm | 400 mm | 400 mm |
| Wheelbase | 968 mm | 969 mm | 970 mm | 977 mm | 994 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 70 mm | 67 mm |
| Standover Height | 702 mm | 724 mm | 742 mm | 770 mm | 800 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
S5 Force eTap AXS is part of the Cervelo S5 model. Cervélo released 40 bikes variations of this model so far. Take a sneak peek at all Cervelo S5 bikes models from 2022, by clicking here.
Model range prices
Cervélo S5 Rival eTap AXS 2022 is the most affordable bike of this model and has a price of 6900$. On the other hand, Cervélo S5 Dura Ace Di2 2022, is the most expensive and costs 12000$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Aero bikes
According to our calculations, the average cost of an Aero bike that is reliable is 4211$. However, you could also get a good Aero bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Cervélo released this model in 2022, its price was 8400$. Comparing the average cost of an Aero bike to this one, you will see that S5 Force eTap AXS price is 99.48% more expensive.
S5 Force eTap AXS components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the S5 Force eTap AXS bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
