Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 700c -
Suspension Rigid
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber
Suspension Fork
Cervélo All-Carbon, Tapered S5 fork
Cockpit
Headset
FSA IS2 1x1/8 - 1x3/8
Seat
Seatpost
Cervélo Carbon, Aero SP17
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.351 mm | 1.38 mm | 1.411 mm | 1.441 mm | 1.466 mm | 1.494 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 579 mm | 580 mm | 577 mm | 588 mm | 604 mm | 618 mm |
| Rake | 53 mm | 53 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 63 mm | 53 mm | 57 mm | 55 mm | 55 mm | 56 mm |
| Stack | 496 mm | 519 mm | 542 mm | 565 mm | 588 mm | 611 mm |
| Reach | 367 mm | 376 mm | 384 mm | 392 mm | 401 mm | 409 mm |
| Top Tube Length | 519 mm | 535 mm | 550 mm | 565 mm | 581 mm | 596 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 70.5 ° | 72.2 ° | 73.1 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 99 mm | 117 mm | 135 mm | 157 mm | 181 mm | 205 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 974 mm | 975 mm | 972 mm | 983 mm | 999 mm | 1013 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 697 mm | 720 mm | 741 mm | 769 mm | 791 mm | 813 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
S5 Frame is part of the Cervelo S5 model. Cervélo launched 40 frames of this model so far. Take a sneak peek at all Cervelo S5 frames models from 2017, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Aero frames average price
According to our math, the average price for a trustworthy Aero frame is 2657$. However, you could also get a good Aero frame even if you pay a lower amount than the average price. To sum up, when you purchase your frame, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your frame. However, the price you have to pay for a carbon fork is considerably higher.
