Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber
Suspension Fork
Cervélo All-Carbon, Tapered S5 Fork
Drivetrain
Rear Derailleur
SRAM RED eTap AXS 12 spd
Front Derailleur
SRAM RED eTap AXS 12 spd
Shift Levers
SRAM RED eTap AXS HRD 12 spd
Cassette
SRAM RED 12s XG1290, 10-28
Crank
SRAM Red AXS 48/35 with Power Meter
Bottom Bracket
Ceramic Speed Dub
Chain
SRAM RED 12 spd
Wheels
Rims
Reserve 50/65mm DT240 XDR, 24h (F), 24h (R), 21mm IW, Center-Lock, Tubeless Ready
Tires
Vittoria Corsa TLR G2.0 25c
Brakes
Brakes
hydraulicDisc
Cockpit
Stem
Cervélo CS028 Carbon V-Stem
Handlebar
Cervélo AB08 Carbon
Headset
FSA IS2 1 x 1-3/8
Seat
Saddle
Prologo Dimension NACK OR Selle Italia NOVUS BOOST EVO Superflow Carbon
Seatpost
Cervelo Carbon SP20 Seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.39 mm | 1.42 mm | 1.45 mm | 1.47 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 266 mm | 266 mm | 268 mm |
| Front Center | 579 mm | 580 mm | 581 mm | 588 mm | 604 mm |
| Rake | 58 mm | 52 mm | 46 mm | 43 mm | 43 mm |
| Trail | 57.1 mm | 57 mm | 57.1 mm | 57 mm | 57 mm |
| Stack | 491 mm | 514 mm | 537 mm | 560 mm | 583 mm |
| Reach | 362 mm | 371 mm | 379 mm | 387 mm | 396 mm |
| Top Tube Length | 515 mm | 530 mm | 545 mm | 560 mm | 576 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 510 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 69 mm | 87 mm | 109 mm | 130 mm | 157 mm |
| Chainstay Length | 400 mm | 400 mm | 400 mm | 400 mm | 400 mm |
| Wheelbase | 968 mm | 969 mm | 970 mm | 977 mm | 994 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 70 mm | 67 mm |
| Standover Height | 702 mm | 724 mm | 742 mm | 770 mm | 800 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
S5 Red eTap AXS is part of the Cervelo S5 model. Cervélo released 40 bikes variations of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
The most economical model, the Cervélo S5 Rival eTap AXS 2022 has a starting price of 6900$. Cervélo S5 Dura Ace Di2 2022 on the other hand is the most expensive at 12000$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Aero bikes average price
Our math shows that the average cost of a dependable Aero bike is 4211$. However, even though the average price of an Aero bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2022 for 12000$. Doing a quick comparison, we notice that S5 Red eTap AXS price is 184.97% more expensive than the average cost of an Aero bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
As for the wheels, Cervélo S5 Red eTap AXS 2022, has a 700c carbon model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Cervélo S5 Red eTap AXS is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
