Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED AXS -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber
Suspension Fork
Cervélo All-Carbon, Tapered S5 Fork
Drivetrain
Rear Derailleur
SRAM Red AXS, 12 speed
Front Derailleur
SRAM Red AXS, 12 speed
Shift Levers
SRAM Red AXS, 12 speed
Cassette
SRAM Red, 10-33, 12 Speed
Crank
SRAM Red AXS, 48/35T, DUB, with power meter
Bottom Bracket
SRAM DUB Ceramic, BBright
Chain
SRAM Red, 12 speed
Wheels
Rims
Rear: Reserve 63, 24.4mm IW, Zipp ZR1 SS,12x142mm, XDR freehub, 24h, centerlock, tubeless compatible Front: Reserve 52, 25.4 IW, Zipp ZR1 SS, 24H, centerlock, tubeless compatible
Tires
Vittoria Corsa TLR G 700x28c
Brakes
Brakes
SRAM Red
Cockpit
Stem
Cervélo ST35 Carbon
Handlebar
Cervélo HB14 Carbon
Headset
FSA IS2 1-1/8 x 1-3/8
Seat
Saddle
Selle Italia NOVUS BOOST EVO SuperFlow Carbon
Seatpost
Cervélo SP20 Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.39 mm | 1.42 mm | 1.45 mm | 1.47 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 266 mm | 266 mm | 268 mm |
| Front Center | 579 mm | 580 mm | 581 mm | 588 mm | 604 mm |
| Rake | 58 mm | 52 mm | 46 mm | 43 mm | 43 mm |
| Trail | 56.1 mm | 56.1 mm | 56.2 mm | 56.2 mm | 56.2 mm |
| Stack | 491 mm | 514 mm | 537 mm | 560 mm | 583 mm |
| Reach | 362 mm | 371 mm | 379 mm | 387 mm | 396 mm |
| Top Tube Length | 515 mm | 530 mm | 545 mm | 560 mm | 576 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 510 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 69 mm | 87 mm | 109 mm | 130 mm | 157 mm |
| Chainstay Length | 400 mm | 400 mm | 400 mm | 400 mm | 400 mm |
| Wheelbase | 968 mm | 969 mm | 970 mm | 977 mm | 994 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 70 mm | 67 mm |
| Standover Height | 710 mm | 731 mm | 749 mm | 777 mm | 808 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
S5 Red eTap AXS is a Cervelo S5 model. Cervélo launched 40 bikes of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Cervélo S5 Rival eTap AXS 2023 is the most affordable bike of this model and has a price of 6900$. On the other hand, Cervélo S5 Red eTap AXS 2023, is the most expensive and costs 13000$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Aero bikes average price
According to our calculations, the average cost of an Aero bike that is reliable is 4211$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Aero bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Cervélo released this model in 2023, its price was 13000$. Comparing the average cost of an Aero bike to this one, you will see that S5 Red eTap AXS price is 208.72% higher.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The wheels on S5 Red eTap AXS are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The S5 Red eTap AXS comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
