Chromag Doctahawk Frame 2023

Bike details

Overview

Key information split into simple groups.

Frame summary

Category
- Mountain
- |
- Enduro
Frame Steel
Wheels 29"
Suspension Full

Sizing

Recommended size guide.

SM
155cm - 165cm
MD
163cm - 174cm
MD/LG
172cm - 183cm
LG
181cm - 192cm
XL
190cm - 200cm

Parts list

Components

Main components, grouped by system.

Bike components

Drivetrain

Bottom Bracket

92mm Press Fit (PF92)*

Cockpit

Headset

44-56 Semi Integrated

Seat

Seatpost

31.6mm

Fit data

Geometry

Numbers for sizing and ride feel.

Size	SM	MD	MD/LG	LG	XL
Stack Reach Ratio	1.48 mm	1.41 mm	1.35 mm	1.3 mm	1.25 mm
Bottom Bracket Height	323 mm	323 mm	323 mm	323 mm	323 mm
Front Center	780 mm	802 mm	828 mm	862 mm	892 mm
Rake	38 mm	38 mm	42 mm	46 mm	46 mm
Trail	152 mm	152 mm	148 mm	143 mm	143 mm
Stack	645 mm	645 mm	645 mm	654 mm	663 mm
Reach	436 mm	458 mm	479 mm	504 mm	529 mm
Top Tube Length	588 mm	609 mm	630 mm	658 mm	685 mm
Seat Tube Angle	76.5 °	76.5 °	76.5 °	76.5 °	76.5 °
Seat Tube Length	356 mm	382 mm	419 mm	445 mm	482 mm
Head Tube Angle	62.5 °	62.5 °	62.5 °	62.5 °	62.5 °
Head Tube Length	105 mm	105 mm	105 mm	115 mm	125 mm
Chainstay Length	432 mm	432 mm	432 mm	442 mm	442 mm
Wheelbase	1208 mm	1230 mm	1256 mm	1300 mm	1330 mm
Bottom Bracket Drop	48 mm	48 mm	48 mm	48 mm	48 mm
Standover Height	676 mm	701 mm	737 mm	763 mm	799 mm
Wheels	29"	29"	29"	29"	29"
Rider Min Height	155 cm	163 cm	172 cm	181 cm	190 cm
Rider Max Height	165 cm	174 cm	183 cm	192 cm	200 cm

About this model

Doctahawk Frame is a Chromag Doctahawk model. There are 13 frames that carry this model name. Take a sneak peek at all Chromag Doctahawk frames models from 2023, by clicking here.

Safety

Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.

Enduro frames average price

According to our math, the average price for a trustworthy Enduro frame is 1895$. However, even though the average price of an Enduro frame is lower, you might still be able to get a top-quality frame. To make sure you don’t pay a higher amount than normal for your frame, always do some components analysis and read reviews.

Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1796$. Doing a quick comparison, we notice that Doctahawk Frame price is 5.51% smaller than the average cost of an Enduro frame.

Enduro frames average weight

Enduro frames weigh an average of 3.44 kg (7.58 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.

Doctahawk Frame weighs 3.2 kg (7.05 lbs) and is a bit lighter than the average. In conclusion, the average Enduro frame weighs 7.5% more than Doctahawk Frame.

Overview of components

Sizes

Chromag Doctahawk Frame frame has 5 sizes, in the range of 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
