Chromag Rootdown Ti Frame 2023
2023 Mountain
Estimate price |
3,232$
Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Titanium -
Wheels 29"
Sizing
Recommended size guide.
SM
155cm - 165cm
MD
163cm - 174cm
MD/LG
172cm - 183cm
LG
181cm - 192cm
XL
190cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Bottom Bracket
92mm Press Fit (PF92)*
Cockpit
Headset
44-56 Semi Integrated
Seat
Seatpost
31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.41 mm | 1.38 mm | 1.33 mm | 1.3 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm | 320 mm | 320 mm |
| Front Center | 762 mm | 787 mm | 808 mm | 836 mm | 857 mm |
| Rake | 51 mm | 51 mm | 51 mm | 50 mm | 51 mm |
| Trail | 126 mm | 126 mm | 126 mm | 127 mm | 126 mm |
| Stack | 632 mm | 632 mm | 641 mm | 650 | 659 mm |
| Reach | 423 mm | 448 mm | 465 mm | 489 mm | 505 mm |
| Top Tube Length | 580 mm | 605 mm | 624 mm | 650 | 669 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 368 mm | 406 mm | 431 mm | 456 mm | 494 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 95 mm | 95 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1179 mm | 1204 mm | 1225 mm | 1253 mm | 1274 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 679 mm | 716 mm | 740 mm | 764 mm | 801 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 163 cm | 172 cm | 181 cm | 190 cm |
| Rider Max Height | 165 cm | 174 cm | 183 cm | 192 cm | 200 cm |
About this model
Rootdown Ti Frame completes the Chromag Rootdown model. Chromag released 20 frames variations of this model so far. You can easily view all of the Chromag Rootdown frames models from 2023, here.
Model range prices
Chromag Rootdown Frame 2023 is the most affordable frame of this model and has a price of 879$. On the other hand, Chromag Rootdown Ti Frame 2023, is the most expensive and costs 3232$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail frames average price
Our math shows that the average cost of a dependable Trail frame is 1736$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail frame. To sum up, when you purchase your frame, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2023 for 3232$. Doing a quick comparison, we notice that Rootdown Ti Frame price is 86.18% more expensive than the average cost of a Trail frame.
Rootdown Ti Frame components
Sizes
Chromag Rootdown Ti Frame frame has 5 sizes, in the range of 155 cm – 200 cm (5.09 ft – 6.56 ft). In short, it won’t be difficult to find the right one for you.
