Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
COLUMBUS T800 Carbon Monocoque
Suspension Fork
COLUMBUS Disc 1-1/8” - 1-1/2” Tapered Carbon Monocoque
Drivetrain
Rear Derailleur
Shimano Ultegra / 11 Speed
Shift Levers
Shimano Ultegra
Cassette
Shimano Ultegra / 11-30T
Crank
Shimano Ultegra / 52-36T, Size 170 (XS) 172.5 (S/M/L) 175 (XL)
Bottom Bracket
Shimano / SM-BB72-41
Chain
Shimano Ultegra
Wheels
Rims
Fulcrum 600 DB
Tires
VITTORIA Zaffiro Pro / 700x28c
Brakes
Brakes
Shimano Ultegra / 160mm Front rotor - 140mm Rear rotor
Cockpit
Stem
/
Handlebar
Vision Metron 5D ACR 100-40 (XS/S) 110-42 (M/L) 120-42 (XL)
Headset
IS 52/28.6 | IS 52/40 FSA ACR
Seat
Saddle
SSM Shortfit
Seatpost
CINELLI Carbon Integrated
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.42 mm | 1.41 mm | 1.43 mm | 1.45 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 571 mm | 579 mm | 590 mm | 600 mm | 611 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 68 mm | 66 mm | 62 mm | 59 mm | 56 mm |
| Stack | 504 mm | 520 mm | 531 mm | 552 mm | 573 mm |
| Reach | 358 mm | 366 mm | 377 mm | 386 mm | 395 mm |
| Top Tube Length | 510 mm | 522 mm | 537 mm | 552 mm | 567 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 73 ° |
| Head Tube Length | 110 mm | 125 mm | 135 mm | 155 mm | 175 mm |
| Chainstay Length | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm |
| Wheelbase | 963 mm | 971 mm | 982 mm | 993 mm | 1003 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Pressure Ultegra completes the Cinelli Pressure model. Cinelli released 15 bikes variations of this model so far. Take a sneak peek at all Cinelli Pressure bikes models from 2022, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Aero bikes
According to our math, the average price for a trustworthy Aero bike is 4211$. However, even if your budget is less than the average, you might still be able to get a top-quality Aero bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The wheels on Pressure Ultegra are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Cinelli Pressure Ultegra has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
