Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Columbus Carbon Monocoque
Suspension Fork
Columbus 1-1 / 8 "- 1-1 / 2" Monocoque
Drivetrain
Shift Levers
SHIMANO 105
Cassette
SHIMANO 105 / 11-28T pack
Crank
SHIMANO / 11 Speed ??/ 50-34T Size 170 (XS) 172.5 (S / M / L) 175 (XL)
Bottom Bracket
SHIMANO / BSA 68mm
Chain
KMC
Wheels
Rims
VISION / 622-17
Tires
MICHELIN Dynamic sport / 700x25c
Brakes
Brakes
Standard road caliper
Cockpit
Stem
CINELLI 6061 Stem Size 90 (XS) 100 (S / M / L) 110 (XL)
Handlebar
CINELLI 6061 Handlebar / Ø 31,8 / Drop 131mm - Reach 55mm Size 40 (XS / S) 42 (M / L / XL)
Headset
IS 42 / 28.6 | IS 52/40
Seat
Saddle
CINELLI SSM Monza start / 145mm
Seatpost
Ø31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.43 mm | 1.44 mm | 1.48 mm | 1.48 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 575 mm | 587 mm | 579 mm | 601 mm | 615 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 59 mm | 57 mm | 58 mm | 58 mm | 60 mm |
| Stack | 508 mm | 530 mm | 549 mm | 581 mm | 599 mm |
| Reach | 360 mm | 370 mm | 380 mm | 392 mm | 404 mm |
| Top Tube Length | 498 mm | 518 mm | 538 mm | 563 mm | 581 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 500 mm | 520 mm | 540 mm | 567 mm | 585 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 115 mm | 135 mm | 155 mm | 180 mm | 200 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 973 mm | 984 mm | 976 mm | 998 mm | 1013 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 742 mm | 762 mm | 782 mm | 802 mm | 819 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Veltrix Caliper completes the Cinelli Veltrix model. Cinelli launched 4 bikes of this model so far. Take a sneak peek at all Cinelli Veltrix bikes models from 2019, by clicking here.
Model range prices
Cinelli Veltrix Caliper 2019 is the cheapest bike model and costs 1649$. Cinelli Veltrix Disc 2019 is the most expensive one and costs 1649$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Race bikes average price
If you want an acceptable Race bike you should know that the average price is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1649$. Comparing the average cost of a Race bike to this one, you will see that Veltrix Caliper price is 103.15% lower.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The Veltrix Caliper 2019 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Veltrix Caliper comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
