Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
COLUMBUS XCr Tubeset
Suspension Fork
COLUMBUS Futura Disc 1-1/8” - 1-1/2”
Drivetrain
Rear Derailleur
Shimano Dura-Ace Di2 R9250/ 12 Speed
Shift Levers
Shimano Dura-Ace Di2 R9270
Cassette
Shimano Dura-Ace / 11-30T
Crank
Shimano Dura-Ace / 52-36T, Size 170 (XS) 172.5 (S/M/L) 175 (XL)
Bottom Bracket
FSA T47
Chain
Shimano M9100
Wheels
Rims
Fulcrum Wind 550 DB
Tires
Pirelli Pzero / 700x28c
Brakes
Brakes
Shimano Dura-Ace / 160mm Front rotor - 140mm Rear rotor
Cockpit
Stem
CINELLI NEOS, Size 90 (XS/S) 100 (M) 110 (L/XL)
Handlebar
CINELLI NEOS, Size 40 (XS/S) 42 (M/L/XL)
Headset
ZS 44/28.6 | EC 44/40
Seat
Saddle
Selle Italia Novus
Seatpost
CINELLI NEOS / Ø31.6 / L350
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.3 mm | 1.3 mm | 1.32 mm | 1.35 mm | 1.39 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 265 mm | 265 mm | 268 mm |
| Front Center | 570 mm | 572 mm | 579 mm | 583 mm | 599 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 67 mm | 62 mm | 54 mm | 51 mm | 51 mm |
| Stack | 490 mm | 497 mm | 515 mm | 534 mm | 559 mm |
| Reach | 377 mm | 381 mm | 389 mm | 395 mm | 402 mm |
| Top Tube Length | 514 mm | 524 mm | 544 mm | 559 mm | 579 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 500 mm | 530 mm | 560 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 73 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 98 mm | 104 mm | 121 mm | 139 mm | 172 mm |
| Chainstay Length | 409 mm | 409 mm | 409 mm | 409 mm | 409 mm |
| Wheelbase | 966 mm | 970 mm | 978 mm | 985 mm | 1001 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 71 mm | 71 mm | 68 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
XCR Disc Dura Ace Di2 belongs to the Cinelli Xcr model. 15 bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Race bikes average price
If you want an acceptable Race bike you should know that the average price is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
XCR Disc Dura Ace Di2 components
Fork material
The fork on this bike is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
When leaving the production line, the XCR Disc Dura Ace Di2 model has 700c carbon wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
