Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 700c -
Suspension Rigid
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High Modulus Carbon - 100% MADE IN ITALY
Suspension Fork
Colnago C60 Full Carbon Disc
Drivetrain
Bottom Bracket
Threadfit82.5 - BB86 Required
Cockpit
Headset
Colnago HS-C 1/8" to 1 1/4"
Seat
Seatpost
Colnago Carbon 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 45cm | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.38 mm | 1.38 mm | 1.43 mm | 1.48 mm | 1.52 mm | 1.5 mm | 1.52 mm | 1.57 mm |
| Stack | 511 mm | 519 mm | 523 mm | 542 mm | 560 mm | 577 mm | 586 mm | 603 mm | 623 mm |
| Reach | 371 mm | 375 mm | 378 mm | 378 mm | 379 mm | 380 mm | 391 mm | 396 mm | 398 mm |
| Top Tube Length | 505 mm | 514 mm | 525 mm | 535 mm | 545 mm | 560 mm | 575 mm | 585 mm | 593 mm |
| Seat Tube Angle | 75.49 ° | 75.14 ° | 74.58 ° | 74 ° | 73.57 ° | 72.83 ° | 72.75 ° | 72.75 ° | 72.75 ° |
| Seat Tube Length | 395 mm | 425 mm | 455 mm | 475 mm | 495 mm | 515 mm | 525 mm | 540 mm | 554 mm |
| Head Tube Length | 122 mm | 125 mm | 127 mm | 145 mm | 163 mm | 179 mm | 187 mm | 204 mm | 225 mm |
| Chainstay Length | 392 mm | 394 mm | 397 mm | 400 mm | 402 mm | 404 mm | 407 mm | 408 mm | 409 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
C60 Disc Frameset is part of the Colnago C60 model. Colnago launched 8 frames of this model so far. Take a sneak peek at all Colnago C60 frames models from 2019, by clicking here.
Model range prices
Colnago C60 Frameset 2019 is the cheapest frame model and costs 5899$. Colnago C60 Disc Frameset 2019 is the most expensive one and costs 6199$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Race frames average price
Our math shows that the average cost of a dependable Race frame is 2445$. However, even if your budget is less than the average, you might still be able to get a top-quality Race frame. To sum up, when you purchase your frame, make sure to check if it has reviews, and also do some components research.
This frame was released in 2019 and its price was 6199$. Comparing the average cost of a Race frame to this one, you will see that C60 Disc Frameset price is 153.54% more expensive.
Overview of components
Fork material
The fork on this frame is made out of carbon, so, it’s a great addition to the frame’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
