Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 700c -
Suspension Rigid
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High Modulus Carbon
Suspension Fork
Colnago C64, 1 1/4"-1 1/8", Internal Cable Routing
Drivetrain
Bottom Bracket
Threadfit82.5 - BB86 Required
Cockpit
Headset
Colnago Integrated, 1/8" to 1 1/4"
Seat
Seatpost
Colnago C64 Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 42s | 45cm | 45s | 48cm | 48s | 50cm | 50s | 52cm | 52s | 54cm | 54s | 56cm | 56s | 58cm | 58s | 60cm | 60s |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.36 mm | 1.37 mm | 1.37 mm | 1.38 mm | 1.38 mm | 1.43 mm | 1.43 mm | 1.47 mm | 1.47 mm | 1.51 mm | 1.51 mm | 1.48 mm | 1.48 mm | 1.5 mm | 1.5 mm | 1.53 mm | 1.53 mm |
| Stack | 518 mm | 518 mm | 525 mm | 525 mm | 531 mm | 531 mm | 551 mm | 551 mm | 568 mm | 568 mm | 586 mm | 586 mm | 594 mm | 594 mm | 611 mm | 611 mm | 631 mm | 631 mm |
| Reach | 380 mm | 380 mm | 384 mm | 384 mm | 386 mm | 386 mm | 386 mm | 386 mm | 387 mm | 387 mm | 388 mm | 388 mm | 401 mm | 401 mm | 408 mm | 408 mm | 413 mm | 413 mm |
| Top Tube Length | 513 mm | 513 mm | 523 mm | 523 mm | 533 mm | 533 mm | 543 mm | 543 mm | 553 mm | 553 mm | 568 mm | 568 mm | 585 mm | 585 mm | 597 mm | 597 mm | 608 mm | 608 mm |
| Seat Tube Angle | 75.49 ° | 75.49 ° | 75.14 ° | 75.14 ° | 74.58 ° | 74.58 ° | 74 ° | 74 ° | 73.57 ° | 73.57 ° | 72.83 ° | 72.83 ° | 72.75 ° | 72.75 ° | 72.75 ° | 72.75 ° | 72.75 ° | 72.75 ° |
| Seat Tube Length | 420 mm | 420 mm | 450 mm | 450 mm | 480 mm | 480 mm | 500 mm | 500 mm | 520 mm | 520 mm | 540 mm | 540 mm | 560 mm | 560 mm | 580 mm | 580 mm | 600 mm | 600 mm |
| Head Tube Angle | 70.8 ° | 70.8 ° | 71.15 ° | 71.15 ° | 71.52 ° | 71.52 ° | 71.62 ° | 71.62 ° | 71.92 ° | 71.92 ° | 72.49 ° | 72.49 ° | 72.88 ° | 72.88 ° | 73.12 ° | 73.12 ° | 73.3 ° | 73.3 ° |
| Head Tube Length | 115 mm | 115 mm | 118 mm | 118 mm | 122 mm | 122 mm | 141 mm | 141 mm | 158 mm | 158 mm | 175 mm | 175 mm | 182 mm | 182 mm | 199 mm | 199 mm | 219 mm | 219 mm |
| Chainstay Length | 408 mm | 408 mm | 408 mm | 408 mm | 411 mm | 411 mm | 413 mm | 413 mm | 413 mm | 413 mm | 415 mm | 415 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
C64 Disc Frameset is part of the Colnago C64 model. 24 frames variations carry this model name so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
The most economical model, the Colnago C64 Disc Frameset 2021 has a starting price of 6889$. Colnago C64 Disc MySixty4 Frameset 2021 on the other hand is the most expensive at 7889$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Race frames average price
If you want to purchase a solid Race frame, it is important to know that the average cost is 2445$. However, this doesn’t mean that if you spend less money on a Race frame, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your frame, always do some components analysis and read reviews.
This frame was released in 2021 and its price was 6889$. Comparing the average cost of a Race frame to this one, you will see that C64 Disc Frameset price is 181.76% more expensive.
Overview of components
Fork material
C64 Disc Frameset has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
