Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 700c -
Suspension Rigid
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High Modulus Carbon
Suspension Fork
Colnago Concept Carbon, 1 1/4"-1 1/8"
Drivetrain
Bottom Bracket
Threadfit82.5 - BB86 Required
Cockpit
Headset
Colnago Integrated, 1/8" to 1 1/4"
Seat
Seatpost
Colnago Concept Aero Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 45cm | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.37 mm | 1.37 mm | 1.41 mm | 1.46 mm | 1.49 mm | 1.47 mm | 1.48 mm |
| Stack | 516 mm | 523 mm | 528 mm | 546 mm | 564 mm | 581 mm | 590 mm | 607 mm |
| Reach | 380 mm | 383 mm | 385 mm | 387 mm | 387 mm | 389 mm | 401 mm | 411 mm |
| Top Tube Length | 513 mm | 522 mm | 530 mm | 543 mm | 553 mm | 568 mm | 583 mm | 599 mm |
| Seat Tube Angle | 75.5 ° | 75.1 ° | 74.6 ° | 74 ° | 73.6 ° | 72.8 ° | 72.8 ° | 72.8 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70.8 ° | 71.1 ° | 71.5 ° | 71.6 ° | 71.9 ° | 72.5 ° | 72.9 ° | 73.1 ° |
| Head Tube Length | 122 mm | 125 mm | 127 mm | 145 mm | 163 mm | 179 mm | 187 mm | 204 mm |
| Chainstay Length | 402 mm | 404 mm | 407 mm | 409 mm | 410 mm | 412 mm | 415 mm | 416 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Concept Frameset is a Colnago Concept model. 12 frames variations carry this model name so far. Take a sneak peek at all Colnago Concept frames models from 2021, by clicking here.
Model range prices
The most economical model, the Colnago Concept Frameset 2021 has a starting price of 4499$. Colnago Concept Disc Frameset 2021 on the other hand is the most expensive at 4699$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Aero frames
According to our math, the average price for a trustworthy Aero frame is 2657$. However, this doesn’t mean that if you spend less money on an Aero frame, you couldn’t get a decent one. In short, before purchasing your ideal frame do some research about its components, and also check for reviews online.
This frame was released in 2021 and its price was 4499$. Comparing this to the average Aero frame price, we see that the price is 69.33% higher.
Overview of components
Fork material
The fork on this frame is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
