Commençal META POWER TR SHIMANO OHLINS EDITION 2022
2022 E-bike
Estimate price |
6,500$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork Öhlins RXF36
-
Groupset XT, Shimano -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery SHIMANO BT-E8036, 630Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
2022 META POWER TR, 140 mm, 29'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings
Suspension Fork
OHLINS RXF36 m.2 Air, 150 mm travel, 29", TTX 18 damper, Ramp Up chamber, LSC, HSC, rebound, Boost (15 x 110 mm), 44 mm offset
Rear Shock
OHLINS TTX2 Air, 210 x 55 mm, LSC, HSC, rebound
Drivetrain
Rear Derailleur
SHIMANO XT, 12s
Shift Levers
SHIMANO XT, 12s
Cassette
SHIMANO XT, 12s, 10-51t
Crank
SHIMANO FC-M8150, 160 mm crank arms
Bottom Bracket
SHIMANO E-BIKE
Chain
SHIMANO XT, 12s
Chain Guide
RIDE ALPHA EP8, 32-34t
Wheels
Front Hub
Rear: DT SWISS 350 - Front: DT SWISS 350, Rear: 28h, sealed bearings, e-bike specific - Front: 28h, sealed bearings
Rear Hub
Rear: DT SWISS 350 - Front: DT SWISS 350, Rear: 28h, sealed bearings, e-bike specific - Front: 28h, sealed bearings
Rims
Rear: DT SWISS HX1700 Spline - Front: DT SWISS HX1700 Spline, Rear: 29'', 28h, welded, 30 mm inner width - Front: 29'', 28h, welded, 30 mm inner width
Tires
Rear: SCHWALBE Nobby Nic - Front: SCHWALBE Magic Mary, Rear: 29"x2.4", Super Trail, Addix SpeedGrip, Tubeless Easy - Front: 29"x2.4", Super Trail, Addix Soft, Tubeless Easy
Brakes
Brakes
SHIMANO XT, 4 pistons, I-Spec EV compatible
Cockpit
Stem
RIDE ALPHA Freeride 40, 40 mm extension, 31,8 mm
Handlebar
RIDE ALPHA R20 POWER on S - RIDE ALPHA R27 POWER on M / L / XL, Internal Di2 cable routing - 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
Grips
ODI Elite Motion, Soft pro compound, single clamp, black
Headset
ACROS ZS56 / ZS66, Alloy cups, sealed bearings
Seat
Saddle
FIZIK Terra Aidon X3, Kium Mobius rails
Seatpost
KS Lev Integra, 31.6 mm, travel: 125 mm on S, 175 mm on M/L, 200 mm on XL, SouthPaw alloy remote
Motor & Battery
Motor
SHIMANO DU-EP800, Max. torque: 85N.m, 250W
Battery
SHIMANO BT-E8036, 630Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.39 mm | 1.33 mm | 1.34 mm | 1.27 mm | 1.28 mm | 1.2 mm | 1.22 mm |
| Bottom Bracket Height | 353 mm | 349 mm | 353 mm | 349 mm | 353 mm | 349 mm | 353 mm | 349 mm |
| Front Center | 778 mm | 778 mm | 800 mm | 800 mm | 827 mm | 827 mm | 852 mm | 852 mm |
| Rake | 54 mm | 53 mm | 53 mm | 53 mm | 53 mm | 53 mm | 53 mm | 53 mm |
| Trail | 119 mm | 123 mm | 120 mm | 123 mm | 120 mm | 123 mm | 120 mm | 123 mm |
| Stack | 601 mm | 604 mm | 606 mm | 609 mm | 610 mm | 613 mm | 610 mm | 613 mm |
| Reach | 437 mm | 433 mm | 457 mm | 453 mm | 482 mm | 478 mm | 507 mm | 503 mm |
| Top Tube Length | 576 mm | 577 mm | 597 mm | 598 mm | 623 mm | 624 mm | 648 mm | 649 mm |
| Seat Tube Angle | 77.5 ° | 77.1 ° | 77.5 ° | 77.1 ° | 77.5 ° | 77.1 ° | 77.5 ° | 77.1 ° |
| Seat Tube Length | 380 mm | 380 mm | 420 mm | 420 mm | 440 mm | 440 mm | 460 mm | 460 mm |
| Head Tube Angle | 64.5 ° | 64.1 ° | 64.5 ° | 64.1 ° | 64.5 ° | 64.1 ° | 64.5 ° | 64.1 ° |
| Head Tube Length | 120 mm | 120 mm | 125 mm | 125 mm | 130 mm | 130 mm | 130 mm | 130 mm |
| Chainstay Length | 450 mm | 451 mm | 450 mm | 451 mm | 450 mm | 451 mm | 450 mm | 451 mm |
| Wheelbase | 1227 mm | 1228 mm | 1249 mm | 1250 mm | 1276 mm | 1277 mm | 1301 mm | 1302 mm |
| Bottom Bracket Drop | 21 mm | 25 mm | 21 mm | 25 mm | 21 mm | 25 mm | 21 mm | 25 mm |
| Standover Height | 754 mm | 754 mm | 756 mm | 756 mm | 759 mm | 759 mm | 762 mm | 762 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
Model Overview
META POWER TR SHIMANO OHLINS EDITION completes the Commencal E Meta Power model. 89 e-bikes variations carry this model name so far. You can easily view all of the Commencal E Meta Power e-bikes models from 2022, here.
Model range prices
Commençal META POWER 29 TEAM 2022 is the most economical model, with a starting price of 5700$. Commençal META POWER SX SHIMANO SIGNATURE 2022 on the other hand costs 9344$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail e-bikes
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, this doesn’t mean that if you spend less money on a Trail e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
This e-bike was released in 2022 and its price was 6500$. Comparing the average cost of a Trail e-bike to this one, you will see that META POWER TR SHIMANO OHLINS EDITION price is 93.16% more expensive.
Overview of components
Fork
The fork installed on this bike is the Öhlins RXF36 model. The travel on this model is 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
From the factory, it comes with the OHLINS TTX2 Air rear shock model, which has a travel of 140mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the META POWER TR SHIMANO OHLINS EDITION e-bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Commençal META POWER TR SHIMANO OHLINS EDITION is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Dropper post
Commençal META POWER TR SHIMANO OHLINS EDITION includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
