Commençal META TR 29 OHLINS EDITION AXS 2021
2021 Mountain
Estimate price |
6,500$
Weight | 15 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork Öhlins RXF36
-
Groupset GX Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 172cm
MD
169cm - 182cm
LG
179cm - 192cm
XL
189cm - 203cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
2021 Meta TR 29, 140 mm travel, 29'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings
Suspension Fork
ÖHLINS RXF 36 M.2 Air, 150 mm, 29", TTX18 cartridge, HSC 3 positions, LSC, rebound Boost (15 x 110 mm), 44 mm offset
Rear Shock
ÖHLINS TTX1 Air, 210 x 55 mm, climb mode, Adjustable HSC (High-Speed Compression), LSC (Low-Speed Compression) and Rebound damping
Drivetrain
Rear Derailleur
SRAM GX Eagle AXS, 12sp, Electrical, with battery
Shift Levers
SRAM GX Eagle AXS, 12sp, Electrical, with battery
Cassette
SRAM GX Eagle, 12s, 10-52t
Crank
SRAM GX Eagle, 170 mm crank arms, DUB, Boost, Chainring: SRAM GX Eagle, 32t, Narrow-Wide
Bottom Bracket
SRAM DUB, Pressfit
Chain
SRAM GX Eagle, 12s
Wheels
Front Hub
Rear: DT SWISS 350 - Front: DT SWISS 350, Rear: 28h, 36t ratchet, sealed bearings - Front: 28h, sealed bearings
Rear Hub
Rear: DT SWISS 350 - Front: DT SWISS 350, Rear: 28h, 36t ratchet, sealed bearings - Front: 28h, sealed bearings
Rims
DT SWISS XM1700 Spline, 29'', 28h, 30 mm inner width
Tires
Rear: MAXXIS DISSECTOR, 29 x 2.40 WT - Front: MAXXIS DISSECTOR, 29 x 2.40 WT, Rear: 3C MaxxTerra EXO+ TR - Front: 3C MaxxTerra EXO+ TR
Brakes
Brakes
SHIMANO XT, 4 pistons, I-Spec EV compatible, Rotors: SHIMANO RT-MT900 203 mm, Centerlock, Ice Technology Freeza, integrated magnet
Cockpit
Stem
RIDE ALPHA Freeride 50, 50 mm extension, 31,8 mm
Handlebar
RIDE ALPHA R27, 31,8 mm, 780 mm width, 31,8 mm, Alloy 7050
Grips
YES
Headset
ACROS ZS44 / ZS56, Alloy cups, sealed bearings
Seat
Saddle
FIZIK Terre Alpaca X5, Wingflex rails
Seatpost
ROCKSHOX reverb AXS, 31.6 mm 125 mm on S, 150 mm on M, 170 mm on L/XL, Electrical, with battery
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.36 mm | 1.3 mm | 1.24 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 770 mm | 797 mm | 824 mm | 851 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 132 mm | 132 mm | 132 mm | 132 mm |
| Stack | 623 mm | 627 mm | 631 mm | 635 mm |
| Reach | 437 mm | 462 mm | 487 mm | 512 mm |
| Top Tube Length | 563 mm | 589 mm | 615 mm | 641 mm |
| Seat Tube Angle | 78.6 ° | 78.6 ° | 78.6 ° | 78.6 ° |
| Seat Tube Length | 380 mm | 420 mm | 440 mm | 460 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 110 mm | 115 mm | 120 mm | 125 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1200 mm | 1227 mm | 1254 mm | 1281 mm |
| Bottom Bracket Drop | 33 mm | 33 mm | 33 mm | 33 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 169 cm | 179 cm | 189 cm |
| Rider Max Height | 172 cm | 182 cm | 192 cm | 203 cm |
About this model
META TR 29 OHLINS EDITION AXS belongs to the Commencal Meta Tr model. There are 61 bikes that carry this model name. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Commençal META TR 29 ORIGIN BRG 2021 is the most economical model, with a starting price of 2499$. Commençal META TR 29 OHLINS EDITION AXS 2021 on the other hand costs 6500$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2021 for 6500$. Doing a quick comparison, we notice that META TR 29 OHLINS EDITION AXS price is 135.34% higher than the average cost of a Trail bike.
Average weight for Trail bikes
On a deeper look, we notice that the average weight of a Trail bike is 12.98 kg (28.62 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Commençal META TR 29 OHLINS EDITION AXS it’s weighing 15 kg (33.07 lbs). At this weight, is much heavier than average. In short, the average Trail bike weight is 15.56% lower than this one.
META TR 29 OHLINS EDITION AXS components
Fork
The Öhlins RXF36 is included from the factory. It has a travel distance of 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
As for the rear shock, this bike has the ÖHLINS TTX1 Air model, with a travel of 140mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
As for the wheels, Commençal META TR 29 OHLINS EDITION AXS 2021, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The META TR 29 OHLINS EDITION AXS comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 160 cm – 203 cm (5.25 ft – 6.66 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Commençal model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
