Conway Cairon S 4.0 Hardtail, Diamant 2023
2023 E-bike
Estimate price |
4,587$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork RST BLADE
-
Groupset SX Eagle -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery BOSCH "Powertube 750", lithium-ion with BMS, 750 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CONWAY Intube Bosch, aluminum
Suspension Fork
RST "Blade Air TNL", 120 mm
Drivetrain
Rear Derailleur
SRAM "SX Eagle", 12speed
Shift Levers
SRAM "SX Eagle Trigger", single click
Crank
MIRANDA "Classic Gen4", 165 mm
Bottom Bracket
Bosch, press-fit
Pedals
VP "VPE-506"
Wheels
Rims
RODI "Ready 30"
Spokes
Niro
Tires
SCHWALBE "Tough Tom", 60-622
Brakes
Brakes
TEKTRO "T-390"
Brake Levers
TEKTRO "T-390"
Cockpit
Stem
CONWAY, 31.8mm, 75mm
Handlebar
CONWAY "Riser", Ø 31.8, 720 mm
Seat
Saddle
SELLE ROYAL "Vivo Athletic Ergo", He
Seatpost
CONWAY Patent, 31.6mm, 350mm
Motor & Battery
Motor
BOSCH mid-engine Gen.4 "Performance CX", 36 V, 250 W
Battery
BOSCH "Powertube 750", lithium-ion with BMS, 750 Wh
Charger
Bosch 4 Ah
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.53 mm | 1.49 mm | 1.41 mm | 1.38 mm |
| Stack | 642 mm | 642 mm | 651 mm | 651 mm | 660 mm |
| Reach | 396 mm | 419 mm | 438 mm | 461 mm | 480 mm |
| Top Tube Length | 578 mm | 593 mm | 613 mm | 633 mm | 653 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 410 mm | 450 mm | 490 mm | 530 mm | 570 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm | 130 mm | 140 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
Cairon S 4.0 Hardtail, Diamant is a Conway E Cairon model. There are 351 e-bikes that carry this model name. You can easily view all of the Conway E Cairon e-bikes models from 2023, here.
Model range prices
Conway Cairon TF 1.7 wave 2023 is the most affordable e-bike of this model and has a price of 2646$. On the other hand, Conway Cairon SUV FS 7.7 2023, is the most expensive and costs 5823$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail e-bikes average price
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2023 for 4235$. Comparing this to the average Trail e-bike price, we see that the price is 25.85% more expensive.
Cairon S 4.0 Hardtail, Diamant components
Fork
Conway Cairon S 4.0 Hardtail, Diamant 2023 e-bike is equipped with the RST BLADE fork, and has 120mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When it comes to wheels, the Cairon S 4.0 Hardtail, Diamant e-bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
