Conway Cairon TF 1.7 2022
2022 E-bike
Estimate price |
2,866$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Fork RST -
Groupset Nexus, FSA -
Suspension Hardtail -
Motor Bosch 250W 50Nm mid-drive -
Battery "Powerpack 400", 400 Wh, -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium
Suspension Fork
RST "Blaze T", 80 mm
Drivetrain
Shift Levers
SHIMANO "Nexus SL-C3000"
Cassette
SHIMANO, 18 Z.
Crank
FSA "CK-200", 170 mm
Wheels
Front Hub
SHIMANO "HB-TX505" QR
Rear Hub
SHIMANO "Nexus SG-C3001" 7-Gg. LL
Rims
CONWAY Hohlkammer "X17", Disc
Tires
CONTINENTAL "Contact Urban", 50-622, Reflex
Brakes
Brakes
SHIMANO "BR-MT200"
Cockpit
Handlebar
HUMPERT "Ergotec Ladytown", Ø 31,8, 620 mm
Seat
Saddle
SELLE ROYAL "Vivo Moderat Ergo", Da
Seatpost
HUMPERT "Ergotec SP10", 350 mm
Motor & Battery
Motor
BOSCH Gen.3 “Active Line PLUS”, 36 V,
Battery
"Powerpack 400", 400 Wh,
Remote
Intuvia
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.65 mm | 1.57 mm | 1.57 mm | 1.49 mm |
| Stack | 643 mm | 643 mm | 662 mm | 662 mm |
| Reach | 389 mm | 409 mm | 423 mm | 443 mm |
| Top Tube Length | 583 mm | 603 mm | 623 mm | 643 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm | 540 mm |
| Head Tube Length | 68 mm | 68 mm | 68 mm | 68 mm |
| Chainstay Length | 488 mm | 488 mm | 488 mm | 488 mm |
| Wheelbase | 1151 mm | 1171 mm | 1192 mm | 1212 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Cairon TF 1.7 belongs to the Conway E Cairon model. 281 e-bikes variations carry this model name so far. You can easily view all of the Conway E Cairon e-bikes models from 2022, here.
Model range prices
Conway Cairon TF 1.7 2022 is the most affordable e-bike of this model and has a price of 2653$. On the other hand, Conway Cairon SUV FS 5.7 2022, is the most expensive and costs 5096$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Touring e-bikes average price
Our math shows that the average cost of a dependable Touring e-bike is 2429$. However, you could also get a good Touring e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2022 and its price was 2653$. In conclusion, this e-bike price is 9.22% higher than the price of the average Touring e-bike.
Cairon TF 1.7 components
Fork
The RST is included from the factory. It has a travel distance of mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
Cairon TF 1.7 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When it comes to wheels, the Cairon TF 1.7 e-bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Conway Cairon TF 1.7 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
