Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
aluminium, diamond, 49cm
Suspension Fork
28", carbon, tapered 1 1/8" - 1.5", 300mm shaft, flat mount, black
Drivetrain
Rear Derailleur
SHIMANO "Sora" RD-R3000
Front Derailleur
SHIMANO "Sora" FD-R3000
Shift Levers
SHIMANO "Sora ST-R3000"
Cassette
SHIMANO "Alivio" CS-HG400, 9-speed, 11-34 teeth
Crank
SHIMANO "Sora" FC-R345, 170mm, 34/50 teeth, 9-speed
Bottom Bracket
SHIMANO "BB-ES300", Octalink, BSA thread, axle length: 113mm, housing width: 86mm
Wheels
Front Hub
FORMULA "RX512", 12 x 100mm, 6-hole, 32 holes, thru axle, black
Rear Hub
FORMULA "RX300", 12 x 142mm, 6-hole, 11-peed HG, 32 holes, thru axle, black
Rims
MACH1 "Gravel 19", 19-622, 32 holes, disc brake, black
Spokes
Niro schwarz
Tires
CONTINENTAL "Terra Trail", 40-622
Brakes
Brakes
mechanic disc brake
Brake Levers
SHIMANO "Sora", ST-R300-L / ST-R3000-R, 2-/9-speed
Cockpit
Stem
CONWAY "GRV A-Head", 1 1/8", 31,8mm handlebar clamp, 80mm long, angle 7°, black
Handlebar
CONWAY "GRV Bar", 400mm, Ø 31,8mm, reach 70mm, drop 125mm, flare 6°, black
Grips
FIZIK "Tempo Microtex Bondcush Soft", black
Headset
GLORY WHEEL IS42/28,6 / IS52/40, 1 1/8" - 1,5"
Seat
Saddle
SELLE ROYAL "1220"
Seatpost
CONWAY, Ø 27,2mm, 350mm long, black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.43 mm | 1.44 mm | 1.44 mm |
| Stack | 554 mm | 568 mm | 593 mm | 614 mm |
| Reach | 382 mm | 398 mm | 411 mm | 425 mm |
| Top Tube Length | 540 mm | 560 mm | 580 mm | 600 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 490 mm | 510 mm | 530 mm | 550 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° |
| Head Tube Length | 130 mm | 145 mm | 170 mm | 190 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
GRV 3.0 diamond is part of the Conway Grv model. Conway launched 48 bikes of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
The most economical model, the Conway GRV 4.0 C diamond 2023 has a starting price of 1693$. Conway GRV 12.0 2023 on the other hand is the most expensive at 3599$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Conway GRV 3.0 diamond price was 1693$. In conclusion, this bike price is 45.42% smaller than the price of the average Gravel bike.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When leaving the production line, the GRV 3.0 diamond model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The GRV 3.0 diamond has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
GRV 3.0 diamond comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
