Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork RST VOLANT
-
Groupset Acera, Shimano -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium
Suspension Fork
RST "Volant ML", 63mm
Drivetrain
Rear Derailleur
SHIMANO "Acera RD-360", 8speed
Shift Levers
SHIMANO "ST-EF505"
Cassette
SHIMANO "HG31", 11-34 Z.
Crank
SHIMANO "FC-TY301", 28/38/48 Z. 170 mm
Wheels
Front Hub
SHIMANO Nabendynamo "DH3D37" QR
Rear Hub
SHIMANO "FH-TX505" QR
Rims
CONWAY Hohlkammer "X11", Disc
Tires
CONTINENTAL "Ride Tour", 47-622, Reflex
Brakes
Brakes
SHIMANO "BR-MT200"
Cockpit
Handlebar
CONWAY Riser, 700 mm
Seat
Saddle
SELLE ROYAL "Shadow"
Seatpost
CONWAY Patent, 31,6 mm, 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.6 mm | 1.63 mm |
| Stack | 622 mm | 636 mm | 655 mm |
| Reach | 391 mm | 398 mm | 403 mm |
| Top Tube Length | 583 mm | 593 mm | 603 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 450 mm | 500 mm | 550 mm |
| Head Tube Length | 71 mm | 71 mm | 71 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1072 mm | 1082 mm | 1094 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
TS 4.0 Trapez is part of the Conway Ts model. There are 37 bikes that carry this model name. Take a sneak peek at all Conway Ts bikes models from 2023, by clicking here.
Model range prices
Conway TS 3.0 ladies, trapeze 2023 is the cheapest bike model and costs 721$. Conway TS 6.0 Trapez 2023 is the most expensive one and costs 1220$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Hybrid bikes
If you want to purchase a solid Hybrid bike, it is important to know that the average cost is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Conway released this model in 2023, its price was 848$. Comparing this to the average Hybrid bike price, we see that the price is 50.89% higher.
Overview of components
Fork
Conway TS 4.0 Trapez 2023 bike is equipped with the RST VOLANT fork, and has 63mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When leaving the production line, the TS 4.0 Trapez model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Conway TS 4.0 Trapez is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Conway TS 4.0 Trapez bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
