Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Travel Front 63mm -
Fork RST
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium
Suspension Fork
RST "Volant Air TNL", 63mm
Drivetrain
Rear Derailleur
SHIMANO "Deore XT RD-T8000", 10 speed
Shift Levers
SHIMANO "Deore SL-T6000"
Cassette
SHIMANO "HG500", 11-34 Z.
Crank
SHIMANO "FC-T6010", 26/36/48 Z. 175 mm
Wheels
Front Hub
SHIMANO Nabendynamo "DH3D37" QR
Rear Hub
SHIMANO "FH-TX505" QR
Rims
CONWAY Hohlkammer "X11", Disc
Tires
CONTINENTAL "Ride Tour", 47-622, Reflex
Brakes
Brakes
TEKTRO "HD-T280"
Cockpit
Handlebar
CONWAY Riser, 700 mm
Seat
Saddle
SELLE ROYAL "Shadow"
Seatpost
CONWAY Patent, 31,6 mm, 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.6 mm | 1.63 mm |
| Stack | 622 mm | 636 mm | 655 mm |
| Reach | 391 mm | 398 mm | 403 mm |
| Top Tube Length | 583 mm | 593 mm | 603 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 450 mm | 500 mm | 550 mm |
| Head Tube Length | 71 mm | 71 mm | 71 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1072 mm | 1082 mm | 1094 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
TS 6.0 Trapez completes the Conway Ts model. There are 37 bikes that carry this model name. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Conway TS 3.0 2022 is the most economical model, with a starting price of 721$. Conway TS 6.0 Trapez 2022 on the other hand costs 1220$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Hybrid bikes
If you want to purchase a solid Hybrid bike, it is important to know that the average cost is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2022 and its price was 1220$. If we compare this with the average Hybrid bike cost we notice that the price is 117.08% higher.
Overview of components
Fork
This bike has the RST fork installed. The fork’s travel is 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The TS 6.0 Trapez 2022 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
