Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Alivio, Shimano -
Suspension Rigid -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 aluminum
Suspension Fork
Aluminum with 15mm thru-axle
Drivetrain
Rear Derailleur
Shimano Alivio Shadow
Front Derailleur
Shimano Acero
Shift Levers
Shimano Altus
Cassette
Shimano Alivio, 11-34, 9-speed
Crank
Unavailable
Bottom Bracket
Shimano Octalink
Chain
Shimano HG53
Pedals
Wellgo alloy platform
Wheels
Front Hub
Joytech, 32h
Rear Hub
Joytech, 32h
Rims
Weinmann
Tires
Kenda Kwick Trax, 700 x 35mm
Brakes
Brakes
Shimano M315 hydraulic disc Hydraulic Disc Brake
Brake Levers
Shimano
Cockpit
Stem
Co-op Cycles aluminum
Handlebar
Co-op Cycles aluminum
Headset
FPD cartridge
Seat
Saddle
Selle Royal Shadow + with gel
Seatpost
Co-op Cycles aluminum
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.32 mm | 1.33 mm | 1.36 mm | 1.36 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Stack | 519.4 mm | 528.8 mm | 544.9 mm | 568.5 mm | 594.2 mm |
| Reach | 383.3 mm | 400.6 mm | 410.6 mm | 418.3 mm | 435.5 mm |
| Top Tube Length | 534 mm | 554 mm | 579 mm | 594 mm | 619 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 360 mm | 400 mm | 450 mm | 500 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1038 mm | 1059 mm | 1070 mm | 1085 mm | 1106 mm |
| Standover Height | 680 mm | 710 mm | 743 mm | 772 mm | 817 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
CTY 1.2 completes the Coop Cty model. Co-op launched 23 bikes of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Co-op CTY 1.1 2021 is the most affordable bike of this model and has a price of 599$. On the other hand, Co-op CTY 2.2 2021, is the most expensive and costs 1199$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Hybrid bikes
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, even though the average price of a Hybrid bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Co-op CTY 1.2 price was 999$. Doing a quick comparison, we notice that CTY 1.2 price is 77.76% higher than the average cost of a Hybrid bike.
Overview of components
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
When it comes to wheels, the CTY 1.2 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Co-op CTY 1.2 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
