Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset Alivio, Shimano -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 aluminum
Suspension Fork
Aluminum with 15mm thru-axle
Drivetrain
Rear Derailleur
Shimano Alivio Shadow
Front Derailleur
Shimano Acero
Shift Levers
Shimano Altus
Cassette
Shimano Alivio, 11-34, 9-speed
Crank
Shimano FCT4010 48/36/26
Bottom Bracket
Shimano Octalink
Chain
Shimano HG53
Pedals
Wellgo alloy platform
Wheels
Front Hub
Joytech, 32h
Rear Hub
Joytech, 32h
Rims
Weinmann
Tires
Kenda Kwick Trax, 700 x 35mm
Brakes
Brakes
Shimano M315 hydraulic disc Hydraulic Disc Brake
Brake Levers
Shimano
Cockpit
Stem
Co-op Cycles aluminum
Handlebar
Co-op Cycles aluminum
Headset
FPD cartridge
Seat
Saddle
Selle Royal Shadow + with gel
Seatpost
Co-op Cycles aluminum
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.32 mm | 1.33 mm | 1.36 mm | 1.36 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Stack | 519.4 mm | 528.8 mm | 544.9 mm | 568.5 mm | 594.2 mm |
| Reach | 383.3 mm | 400.6 mm | 410.6 mm | 418.3 mm | 435.5 mm |
| Top Tube Length | 534 mm | 554 mm | 579 mm | 594 mm | 619 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 360 mm | 400 mm | 450 mm | 500 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1038 mm | 1059 mm | 1070 mm | 1085 mm | 1106 mm |
| Standover Height | 680 mm | 710 mm | 743 mm | 772 mm | 817 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
CTY 1.2 completes the Coop Cty model. Co-op launched 23 bikes of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Co-op CTY 1.1 2022 is the cheapest bike model and costs 649$. Co-op CTY 1.2 2022 is the most expensive one and costs 999$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Hybrid bikes average price
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2022 for 999$. Comparing this to the average Hybrid bike price, we see that the price is 77.76% higher.
Overview of components
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When it comes to wheels, the CTY 1.2 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The CTY 1.2 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
