Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 120mm -
Fork RockShox Sektor
-
Groupset Deore, FSA -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Co-op Cycles 6061 aluminum
Suspension Fork
RockShox Sektor RL, 120 millimeters
Rear Shock
RockShox Monarch R Solo Air
Drivetrain
Rear Derailleur
Shimano Deore Shadow +
Front Derailleur
N/A
Shift Levers
Shimano Deore, 10-speed, Rapidfire Plus
Cassette
Shimano 10-speed 11-42T
Crank
FSA Gamma Pro 1X MegaExo
Bottom Bracket
FSA MegaExo
Chain
Shimano Super Narrow, 10-speed
Pedals
Sold separately
Wheels
Front Hub
Shimano Alivio with thru-axle
Rear Hub
Shimano Alivio 12mm thru-axle
Rims
WTB ST i40 TCS 2.0; 26",
Tires
WTB RANGER, 26+ X 2.8
Brakes
Brakes
Tektro Auriga hydraulic disc Hydraulic Disc Brake
Brake Levers
Tektro
Cockpit
Stem
Co-op cycles 6061 aluminum
Handlebar
Co-op double butted aluminum riser
Headset
Internal headset
Seat
Saddle
WTB Volt Sport
Seatpost
X-fusion Manic dropper with remote; 100mm/150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.32 mm | 1.32 mm | 1.28 mm | 1.26 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Stack | 554 mm | 554 mm | 584 mm | 602 mm | 621 mm |
| Reach | 394 mm | 419 mm | 444 mm | 469 mm | 494 mm |
| Top Tube Length | 544 mm | 569 mm | 602 mm | 634 mm | 666 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 360 mm | 395 mm | 430 mm | 465 mm | 500 mm |
| Head Tube Angle | 66 ° | 66 ° | 67 ° | 67 ° | 67 ° |
| Chainstay Length | 427 mm | 427 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1118 mm | 1144 mm | 1175 mm | 1207 mm | 1240 mm |
| Standover Height | 755 mm | 757 mm | 775 mm | 789 mm | 793 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
DRT 3.1 completes the Coop Drt model. 45 bikes variations carry this model name so far. You can easily view all of the Coop Drt bikes models from 2019, here.
Model range prices
Co-op DRT 1.0 2019 is the most economical model, with a starting price of 499$. Co-op DRT 3.2 2019 on the other hand costs 2799$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Co-op released this model in 2019, its price was 2199$. Comparing the average cost of a Trail bike to this one, you will see that DRT 3.1 price is 25.6% lower.
Overview of components
Fork
Co-op DRT 3.1 2019 bike is equipped with the RockShox Sektor fork, and has 120mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When it comes to wheels, the DRT 3.1 bike is equipped with the 26″ aluminum model. These wheels give you great handling over your bike. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Nothing is more important on a bike than its ability to brake properly. Co-op DRT 3.1 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Co-op DRT 3.1 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Co-op model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
