Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 120mm -
Fork RockShox Revelation RC
-
Groupset NX Eagle -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Co-op Cycles 6061 aluminum
Suspension Fork
RockShox Revelation RC, 120 millimeters
Rear Shock
RockShox Monarch R Solo Air
Drivetrain
Rear Derailleur
SRAM NX Eagle; 12-speed
Front Derailleur
N/A
Shift Levers
SRAM NX Eagle, 12-speed
Cassette
SRAM NX 1230 Eagle; 11-50T, 12-speed
Crank
SRAM NX Eagle Dub™
Bottom Bracket
SRAM DUB™
Chain
SRAM NX Eagle, 12-speed
Pedals
Sold separately
Wheels
Front Hub
SRAM MTH 716 15mm with thru-axle
Rear Hub
SRAM MTH 746, 12mm, 11/12-speed with thru-axle
Rims
WTB ST i40 TCS 2.0; 26",
Tires
WTB RANGER, 26 X 2.8
Brakes
Brakes
Shimano BR-MT500 2 piston, post mount hydraulic Hydraulic Disc Brake
Brake Levers
Shimano
Cockpit
Stem
Co-op cycles 6061 aluminum
Handlebar
Co-op double butted aluminum riser
Headset
Internal headset
Seat
Saddle
WTB Volt Sport
Seatpost
X-Fusion Manic Dropper w/remote; 100mm/150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.32 mm | 1.32 mm | 1.28 mm | 1.26 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Stack | 554 mm | 554 mm | 584 mm | 602 mm | 621 mm |
| Reach | 394 mm | 419 mm | 444 mm | 469 mm | 494 mm |
| Top Tube Length | 544 mm | 569 mm | 602 mm | 634 mm | 666 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 360 mm | 395 mm | 430 mm | 465 mm | 500 mm |
| Head Tube Angle | 66 ° | 66 ° | 67 ° | 67 ° | 67 ° |
| Chainstay Length | 427 mm | 427 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1118 mm | 1144 mm | 1175 mm | 1207 mm | 1240 mm |
| Standover Height | 755 mm | 757 mm | 775 mm | 789 mm | 793 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
DRT 3.2 is a Coop Drt model. There are 45 bikes that carry this model name. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Co-op DRT 1.1W 2020 is the cheapest bike model and costs 499$. Co-op DRT 3.3 2020 is the most expensive one and costs 3299$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Co-op DRT 3.2 price was 2799$. Doing a quick comparison, we notice that DRT 3.2 price is 1.34% more expensive than the average cost of a Trail bike.
DRT 3.2 components
Fork
This bike has the RockShox Revelation RC fork installed. The fork’s travel is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When it comes to wheels, the DRT 3.2 bike is equipped with the 26″ aluminum model. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The DRT 3.2 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
DRT 3.2 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
The Co-op model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
