Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Tiagra, Shimano -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec Allroad
Suspension Fork
Corratec Allroad Full Carbon , Material: Carbon
Drivetrain
Rear Derailleur
Shimano Tiagra 10s
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra
Cassette
Shimano HG50 10s , Number of pinions; Ratio: 10s; 11 12 14 16 18 20 22 25 28 32
Crank
Shimano RS460 , Number of chainrings; Ratio: 2s; 46/36
Wheels
Rims
ZZYZX Allroad Wheelset Disc , Rim outer diameter: 28.00 zoll
Tires
Schwalbe G-ONE Allroad , Width: 40 mm, Type of tires: clincher, LiteSkin - light sidewalls for weight savings and reduced rolling resistance, V-Guard - An extremely lightweight and cut-resistant high-tech fiber
Brakes
Brakes
Tektro Spyre Disc front , Size brake disc: 160 mm, Tektro Spyre Disc rear , Size brake disc: 160 mm
Cockpit
Stem
ZZYZX Alloy Stem
Handlebar
ZZYZX SL Alloy Handlebar
Seat
Saddle
Selle San Marco Monza
Seatpost
ZZYZX SL Alloy Seatpost , Outer diameter: 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 49cm | 52cm | 55cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.528 mm | 1.564 mm | 1.585 mm | 1.624 mm | 1.647 mm | 1.681 mm |
| Stack | 550 mm | 571 mm | 588 mm | 609 mm | 626 mm | 647 mm |
| Reach | 360 mm | 365 mm | 371 mm | 375 mm | 380 mm | 385 mm |
| Top Tube Length | 512 mm | 529 mm | 545 mm | 561 mm | 578 mm | 595 mm |
| Seat Tube Angle | 75 ° | 74 ° | 74 ° | 73 ° | 73 ° | 72 ° |
| Head Tube Angle | 69 ° | 70 ° | 70 ° | 71 ° | 71 ° | 72 ° |
| Head Tube Length | 125 mm | 145 mm | 160 mm | 180 mm | 195 mm | 215 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1014 mm | 1022 mm | 1025 mm | 1032 mm | 1037 mm | 1041 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
ALLROAD A2 is part of the Corratec Allroad model. Corratec launched 11 bikes of this model so far. Take a sneak peek at all Corratec Allroad bikes models from 2021, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for General Road bikes
Our math shows that the average cost of a dependable General Road bike is 1915$. However, this doesn’t mean that if you spend less money on a General Road bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
ALLROAD A2 components
Fork material
ALLROAD A2 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
As for the wheels, Corratec ALLROAD A2 2021, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The ALLROAD A2 has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
