Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Ekar -
Suspension Rigid -
Drivetrain 1 × 13 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec Allroad Carbon , Material: Carbon UD 700T
Suspension Fork
Corratec Allroad Carbon Disc
Drivetrain
Rear Derailleur
Campagnolo Ekar
Shift Levers
Campagnolo Ekar
Cassette
Campagnolo Ekar , Number of pinions; Ratio: 13S; 9-42
Crank
Campagnolo Ekar , Number of chainrings; Ratio: 1s; 42
Wheels
Rims
Mavic Allroad Disc , Type of tires: clincher, Material: Alloy S6000
Tires
WTB Riddler , Type of tires: clincher
Brakes
Brakes
Campagnolo Ekar , Size brake disc: 160 mm front, Size brake disc: 160 mm rear
Cockpit
Stem
ZZYZX SL Alloy Stem
Handlebar
ZZYZX SL Carbon Handlebar
Seat
Saddle
Selle Italia Model X
Seatpost
ZZYZX Seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.469 mm | 1.471 mm | 1.537 mm | 1.566 mm | 1.564 mm | 1.549 mm |
| Stack | 523 mm | 537 mm | 561 mm | 584 mm | 602 mm | 621 mm |
| Reach | 356 mm | 365 mm | 365 mm | 373 mm | 385 mm | 401 mm |
| Top Tube Length | 495 mm | 505 mm | 526 mm | 546 mm | 570 mm | 591 mm |
| Seat Tube Angle | 75 ° | 74 ° | 74 ° | 74 ° | 73 ° | 73 ° |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 95 mm | 111 mm | 136 mm | 156 mm | 176 mm | 196 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1015 mm | 1014 mm | 1032 mm | 1038 mm | 1058 mm | 1079 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
ALLROAD C Ekar belongs to the Corratec Allroad model. 11 bikes variations carry this model name so far. You can easily view all of the Corratec Allroad bikes models from 2023, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
General Road bikes average price
If you want an acceptable General Road bike you should know that the average price is 1915$. However, paying less money than this amount doesn’t mean that you couldn’t get a great General Road bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
ALLROAD C Ekar components
Fork material
ALLROAD C Ekar has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on ALLROAD C Ekar are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Corratec ALLROAD C Ekar has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
