Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec Allroad Carbon , Material: Carbon UD 700T
Suspension Fork
Corratec Allroad Carbon Disc
Drivetrain
Rear Derailleur
Shimano GRX RX810 11S
Front Derailleur
Shimano GRX
Shift Levers
Shimano GRX
Cassette
Shimano HG701 , Number of pinions; Ratio: 11s; 11 13 15 17 19 21 23 25 27 30 34
Crank
Shimano GRX , Number of chainrings; Ratio: 2s; 31/48
Wheels
Rims
ZZYZX Allroad Wheelset Disc , Rim outer diameter: 28.00 zoll
Tires
WTB Riddler , Type of tires: clincher
Brakes
Brakes
Shimano GRX , Size brake disc: 160 mm front, Size brake disc: 160 mm rear
Cockpit
Stem
ZZYZX SL Alloy Stem
Handlebar
ZZYZX SL Alloy Handlebar
Seat
Saddle
Selle Italia Model X
Seatpost
ZZYZX Seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.469 mm | 1.471 mm | 1.537 mm | 1.566 mm | 1.564 mm | 1.549 mm |
| Stack | 523 mm | 537 mm | 561 mm | 584 mm | 602 mm | 621 mm |
| Reach | 356 mm | 365 mm | 365 mm | 373 mm | 385 mm | 401 mm |
| Top Tube Length | 495 mm | 505 mm | 526 mm | 546 mm | 570 mm | 591 mm |
| Seat Tube Angle | 75 ° | 74 ° | 74 ° | 74 ° | 73 ° | 73 ° |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 95 mm | 111 mm | 136 mm | 156 mm | 176 mm | 196 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1015 mm | 1014 mm | 1032 mm | 1038 mm | 1058 mm | 1079 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
ALLROAD C2 belongs to the Corratec Allroad model. 11 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
General Road bikes average price
According to our math, the average price for a trustworthy General Road bike is 1915$. However, this doesn’t mean that if you spend less money on a General Road bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When leaving the production line, the ALLROAD C2 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Corratec ALLROAD C2 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
