Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Groupset Alfine, SunRace -
Suspension Rigid -
Drivetrain Internally Geared Hub -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec C29er Disc , Material: Alloy 6061
Suspension Fork
Corratec C29er Disc
Drivetrain
Shift Levers
Shimano Alfine 8s
Cassette
Shimano Alfine CS-500 18T , Number of pinions; Ratio: 8s; 18
Crank
Sunrace S38 , Number of chainrings; Ratio: 1s; 38
Wheels
Rims
ZZYZX Cross Attack 29 front , Rim height: 19 mm, Rim outer diameter: 29.00 zoll, Width outside: 24 mm, Number of spokes: 32, Type of tires: clincher with tubes, ZZYZX Cross Attack 29 rear , Rim height: 19 mm, Rim outer diameter: 29.00 zoll, Width outside: 24 mm, Number of spokes: 32, Type of tires: clincher with tubes
Tires
Continental Contact Cruiser front , Inside diameter: 29.00 zoll, Width: 55 mm, Type of tires: clincher with tubes, Continental Contact Cruiser rear , Inside diameter: 29.00 zoll, Width: 55 mm, Type of tires: clincher with tubes
Brakes
Brakes
Tektro HDT275 front , Size brake disc: 180 mm, Tektro HDT275 rear , Size brake disc: 160 mm
Cockpit
Stem
ZZYZX Speedlifter
Handlebar
ZZYZX Trekking Handlebar
Seat
Saddle
Corratec Classic Leather
Seatpost
ZZYZX SL Alloy Seatpost , Outer diameter: 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 57cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.423 mm | 1.469 mm | 1.485 mm | 1.483 mm | 1.492 mm |
| Stack | 575 mm | 589 mm | 603 mm | 617 mm | 631 mm |
| Reach | 404 mm | 401 mm | 406 mm | 416 mm | 423 mm |
| Top Tube Length | 580 mm | 587 mm | 596 mm | 610 mm | 622 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 140 mm | 155 mm | 170 mm | 185 mm | 200 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1116 mm | mm | 1116 mm | 1103 mm | 1145 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
C29 Base Gent completes the Corratec C29 model. There are 8 bikes that carry this model name. You can easily view all of the Corratec C29 bikes models from 2022, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Commuter bikes
If you want an acceptable Commuter bike you should know that the average price is 762$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Wheels size
The wheels on C29 Base Gent are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. Corratec C29 Base Gent has Mechanical Disc brakes installed. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
