Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Groupset XT, Deore -
Suspension Rigid -
Drivetrain 3 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec C29er Disc , Material: Alloy 6061
Suspension Fork
Corratec C29er Disc
Drivetrain
Rear Derailleur
Shimano T8000 Deore XT
Front Derailleur
Shimano DEORE
Shift Levers
Shimano DEORE
Cassette
Shimano HG50 10s , Number of pinions; Ratio: 10s; 11 13 15 17 19 21 24 28 32 36
Crank
Shimano Deore , Number of chainrings; Ratio: 3s; 48/36/26
Wheels
Rims
ZZYZX Cross Attack 29 front , Rim height: 19 mm, Rim outer diameter: 29.00 zoll, Width outside: 24 mm, Number of spokes: 32, Type of tires: clincher with tubes, ZZYZX Cross Attack 29 rear , Rim height: 19 mm, Rim outer diameter: 29.00 zoll, Width outside: 24 mm, Number of spokes: 32, Type of tires: clincher with tubes
Tires
Continental Contact Cruiser front , Inside diameter: 29.00 zoll, Width: 55 mm, Type of tires: clincher with tubes, Continental Contact Cruiser rear , Inside diameter: 29.00 zoll, Width: 55 mm, Type of tires: clincher with tubes
Brakes
Brakes
Tektro HDT275 front , Size brake disc: 180 mm, Tektro HDT275 rear , Size brake disc: 160 mm
Cockpit
Stem
ZZYZX Speedlifter
Handlebar
ZZYZX Trekking Handlebar
Seat
Saddle
Corratec Classic Leather
Seatpost
ZZYZX SL Alloy Seatpost , Outer diameter: 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 48cm | 51cm | 54cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.479 mm | 1.439 mm | 1.55 mm | 1.512 mm |
| Stack | 590 mm | 590 mm | 623 mm | 623 mm |
| Reach | 399 mm | 410 mm | 402 mm | 412 mm |
| Top Tube Length | 578 mm | 591 mm | 599 mm | 608 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 155 mm | 155 mm | 190 mm | 190 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1103 mm | 1115 mm | 1120 mm | 1129 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
C29 Elite Trapez belongs to the Corratec C29 model. There are 8 bikes that carry this model name. Take a sneak peek at all Corratec C29 bikes models from 2022, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Commuter bikes
According to our calculations, the average cost of a Commuter bike that is reliable is 762$. However, you could also get a good Commuter bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
C29 Elite Trapez components
Wheels size
When it comes to wheels, the C29 Elite Trapez bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The C29 Elite Trapez comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
