Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Suspension Rigid -
Motor Bosch 250W 85Nm mid-drive -
Battery BOSCH PowerTube 750Wh , Energy: 750 wh -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec E-Power C29 SE 3.0 CX7 Belt Sport , Material: Alloy
Suspension Fork
Corratec EP C29 SE 3.0 CX7 Belt Sport , Material: Alloy
Drivetrain
Shift Levers
Enviolo TR
Cassette
Gates Carbon Drive
Crank
ZZYZX E-Power Crank , Number of chainrings; Ratio: 1s; 46
Wheels
Rims
ZZYZX Sport HD front , Rim outer diameter: 29.00 zoll, ZZYZX Sport HD rear , Rim outer diameter: 29.00 zoll
Tires
Continental Contact Cruiser front , Inside diameter: 29.00 zoll, Width: 55 mm, Type of tires: clincher, Continental Contact Cruiser rear , Inside diameter: 29.00 zoll, Width: 55 mm, Type of tires: clincher
Brakes
Brakes
Magura MT Thirty front , Size brake disc: 180 mm, Magura MT Thirty rear , Size brake disc: 180 mm
Cockpit
Stem
ZZYZX SL Alloy Stem
Handlebar
ZZYZX Trekking Handlebar
Seat
Saddle
Corratec Classic Leather
Seatpost
ZZYZX SL Alloy Seatpost , Outer diameter: 30.9 mm
Motor & Battery
Motor
BOSCH Performance Line CX , Max speed: 25 km/h, Power: 250 watt, Torque: 85 Nm (J)
Battery
BOSCH PowerTube 750Wh , Energy: 750 wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 50cm | 55cm |
|---|---|---|---|
| Stack Reach Ratio | 1.583 mm | 1.582 mm | 1.548 mm |
| Stack | 665 mm | 674 mm | 684 mm |
| Reach | 420 mm | 426 mm | 442 mm |
| Top Tube Length | 617 mm | 625 mm | 644 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 170 mm | 180 mm | 190 mm |
| Chainstay Length | 482 mm | 482 mm | 482 mm |
| Wheelbase | 1175 mm | 1185 mm | 1204 mm |
| Wheels | 29" | 29" | 29" |
About this model
C29 SE 3.0 CX7 Belt Trapez is a Corratec E C29 model. Corratec released 6 e-bikes variations of this model so far. You can easily view all of the Corratec E C29 e-bikes models from 2023, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Commuter e-bikes
According to our calculations, the average cost of a Commuter e-bike that is reliable is 2569$. However, even though the average price of a Commuter e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork material
C29 SE 3.0 CX7 Belt Trapez has an aluminum fork, so there won’t be much extra weight added to the e-bike. However, they are not so stiff as carbon forks are.
Wheels size
When it comes to wheels, the C29 SE 3.0 CX7 Belt Trapez e-bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The C29 SE 3.0 CX7 Belt Trapez has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
