Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 180mm -
Travel Rear 180mm -
Fork RockShox ZEB Ultimate
-
Groupset X01 Eagle AXS, XX1 Eagle AXS -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery BOSCH PowerTube 625Wh , What more could you want? The new PowerTube 625 lets you enjoy long and mountainous rides, while still reserving plenty of energy for every adventure. Thanks to a rated capacity of 16.7 Ah and approx. 625 Wh energy content, the lithium-ion battery brings maximum ranges and altitudes within your grasp. Energy: 625 wh, Voltage: 36V, Weight of just approx. 3,5 Kg, Compatible with DualBattery -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec E-Power iLink 180 , Shadow Edge Tube 2.0 - worldwide most stable and safest corratec E-Bike frame. 3.345 gram: Frame weight including all components and paintwork. Full carbon fully including the rear body. 180mm iLink technology. Material: Carbon
Suspension Fork
Rockshox Zeb Ultimate 29" , Suspension travel: 180 mm
Rear Shock
Rockshox Super Deluxe Ultimate
Drivetrain
Rear Derailleur
SRAM AXS Eagle
Shift Levers
SRAM XX1 Eagle AXS
Cassette
SRAM Eagle Black 10-50 , Number of pinions; Ratio: 12s; 10 12 14 16 18 21 24 28 32 36 42 50
Crank
SRAM X-Sync E-Power Crank , Number of chainrings; Ratio: 1s; 34
Wheels
Rims
DT Swiss HX 1501 Spline 29" front , Rim outer diameter: 29.00 zoll, Type of tires: clincher with tubes, DT Swiss HX 1501 Spline 650B rear , Rim outer diameter: 27.50 zoll, Type of tires: clincher with tubes
Tires
Michelin Wild Enduro TLR 29 front , Inside diameter: 29.00 zoll, Type of tires: clincher, Width: 2.4 inch, Michelin Wild Enduro TLR 650B rear , Inside diameter: 27.50 zoll, Type of tires: clincher, Width: 2.8 inch
Brakes
Brakes
SRAM G2 RSC front , Size brake disc: 203 mm, SRAM G2 RSC rear , Size brake disc: 203 mm
Cockpit
Stem
ZZYZX SL Alloy
Handlebar
ZZYZX SL Alloy Handlebar , Width: 800mm
Seat
Saddle
Selle Italia Model X
Seatpost
Rockshox Reverb AXS
Motor & Battery
Motor
BOSCH Performance Line CX , No path too steep, no challenge too great: the Performance Line CX is made for anyone for whom the trail is a second home. eMTB mode will always give you the power you need at precisely the right moment. Max speed: 25 km/h, Power: 250 watt, Torque: 85 Nm (J), Max. support of 340% For powerful propulsion, an extremely sporty riding style and fast sprints. Weight of just approximately 2,9 Kg.
Battery
BOSCH PowerTube 625Wh , What more could you want? The new PowerTube 625 lets you enjoy long and mountainous rides, while still reserving plenty of energy for every adventure. Thanks to a rated capacity of 16.7 Ah and approx. 625 Wh energy content, the lithium-ion battery brings maximum ranges and altitudes within your grasp. Energy: 625 wh, Voltage: 36V, Weight of just approx. 3,5 Kg, Compatible with DualBattery
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 48cm | 52cm |
|---|---|---|---|
| Stack Reach Ratio | 1.354 mm | 1.335 mm | 1.324 mm |
| Stack | 616 mm | 621 mm | 629 mm |
| Reach | 455 mm | 465 mm | 475 mm |
| Top Tube Length | 599 mm | 611 mm | 623 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 86 mm | 97 mm | 106 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1236 mm | 1248 mm | 1262 mm |
| Wheels | 29" | 29" | 29" |
Model Overview
E-Power iLink 180 Factory is a Corratec E E Power model. 97 e-bikes variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro e-bikes
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, you could also get a good Enduro e-bike even if you pay a lower amount than the average price. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
E-Power iLink 180 Factory components
Fork
The RockShox ZEB Ultimate is included from the factory. It has a travel distance of 180mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
As for the rear shock, this e-bike has the Rockshox Super Deluxe Ultimate model, with a travel of 180mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When it comes to wheels, the E-Power iLink 180 Factory e-bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Corratec E-Power iLink 180 Factory has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Dropper post
The Corratec model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
