Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 180mm -
Fork RockShox ZEB Ultimate
-
Groupset X01 Eagle AXS, GX Eagle AXS -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery BOSCH PowerTube 625Wh , Energy: 625 wh -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec E-Power iLink 180 Boost , Material: Carbon
Suspension Fork
Rockshox FS Zeb Ultimate RC2 29" Boost , Suspension travel: 180 mm
Rear Shock
Rockshox Super Deluxe Ultimate
Drivetrain
Rear Derailleur
SRAM AXS Eagle
Shift Levers
SRAM GX AXS Eagle , expanded 520% range, customization with the AXS app
Cassette
SRAM Eagle Black 10-50 , Number of pinions; Ratio: 12s; 10 12 14 16 18 21 24 28 32 36 42 50
Crank
SRAM X-Sync E-Power Crank , Number of chainrings; Ratio: 1s; 34
Wheels
Rims
Mavic E-Deemax S30 front , Rim outer diameter: 29.00 zoll, Type of tires: Tubeless Ready, Mavic E-Deemax S35 rear , Rim outer diameter: 27.50 zoll, Type of tires: Tubeless Ready
Tires
Michelin E-Wild 29 front , Width: 2.60, Inside diameter: 29.00 zoll, Michelin E-Wild 650B rear , Width: 2.80, Inside diameter: 27.50 zoll
Brakes
Brakes
SRAM G2 front , Size brake disc: 203 mm, SRAM G2 RSC rear , Size brake disc: 203 mm
Cockpit
Stem
ZZYZX SL Alloy
Handlebar
ZZYZX SL Alloy Handlebar , Width: 800mm
Seat
Saddle
Selle San Marco Gnd Full-fit
Seatpost
Rockshox Reverb AXS
Motor & Battery
Motor
BOSCH Performance CX Race , Max speed: 25 km/h, Torque: 85 Nm (J)
Battery
BOSCH PowerTube 625Wh , Energy: 625 wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 48cm | 52cm |
|---|---|---|---|
| Stack Reach Ratio | 1.354 mm | 1.335 mm | 1.324 mm |
| Stack | 616 mm | 621 mm | 629 mm |
| Reach | 455 mm | 465 mm | 475 mm |
| Top Tube Length | 599 mm | 611 mm | 623 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 86 mm | 97 mm | 106 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1236 mm | 1248 mm | 1262 mm |
| Wheels | 29" | 29" | 29" |
About this model
E-Power iLink 180 Factory completes the Corratec E E Power model. There are 97 e-bikes that carry this model name. You can get a glimpse at all models from 2023, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Enduro e-bikes average price
According to our calculations, the average cost of an Enduro e-bike that is reliable is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
E-Power iLink 180 Factory components
Fork
This e-bike has the RockShox ZEB Ultimate fork installed. The fork’s travel is 180mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When leaving the production line, the E-Power iLink 180 Factory model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The E-Power iLink 180 Factory comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Dropper post
Corratec E-Power iLink 180 Factory includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
