Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 180mm -
Travel Rear 180mm -
Fork RockShox ZEB Ultimate
-
Groupset X01 Eagle AXS, XX1 Eagle AXS -
Suspension Full -
Motor Bosch 350W 85Nm mid-drive -
Battery BOSCH PowerTube 625Wh , What more could you want? The new PowerTube 625 lets you enjoy long and mountainous rides, while still reserving plenty of energy for every adventure. Thanks to a rated capacity of 16.7 Ah and approx. 625 Wh energy content, the lithium-ion battery brings maximum ranges and altitudes within your grasp. Energy: 625 wh, Voltage: 36V, Weight of just approx. 3,5 Kg, Compatible with DualBattery -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec E-Power iLink 180 , Shadow Edge Tube 2.0 - worldwide most stable and safest corratec E-Bike frame. 3.345 gram: Frame weight including all components and paintwork. Full carbon fully including the rear body. 180mm iLink technology. Material: Carbon
Suspension Fork
Rockshox Zeb Ultimate 29" , Suspension travel: 180 mm
Rear Shock
Rockshox Super Deluxe Ultimate
Drivetrain
Rear Derailleur
SRAM AXS Eagle
Shift Levers
SRAM XX1 Eagle AXS
Cassette
SRAM Eagle Black 10-50 , Number of pinions; Ratio: 12s; 10 12 14 16 18 21 24 28 32 36 42 50
Crank
SRAM X-Sync E-Power Crank , Number of chainrings; Ratio: 1s; 34
Wheels
Rims
DT Swiss HX 1501 Spline 29" front , Rim outer diameter: 29.00 zoll, Type of tires: clincher with tubes, DT Swiss HX 1501 Spline 650B rear , Rim outer diameter: 27.50 zoll, Type of tires: clincher with tubes
Tires
Michelin Wild Enduro TLR 29 front , Inside diameter: 29.00 zoll, Type of tires: clincher, Width: 2.4 inch, Michelin Wild Enduro TLR 650B rear , Inside diameter: 27.50 zoll, Type of tires: clincher, Width: 2.8 inch
Brakes
Brakes
SRAM G2 RSC front , Size brake disc: 203 mm, SRAM G2 RSC rear , Size brake disc: 203 mm
Cockpit
Stem
ZZYZX SL Alloy
Handlebar
ZZYZX SL Alloy Handlebar , Width: 800mm
Seat
Saddle
Selle Italia Model X
Seatpost
Rockshox Reverb AXS
Motor & Battery
Motor
BOSCH Performance Line Speed , Max speed: 45 km/h, Power: 350 watt, Torque: 85 Nm (J)
Battery
BOSCH PowerTube 625Wh , What more could you want? The new PowerTube 625 lets you enjoy long and mountainous rides, while still reserving plenty of energy for every adventure. Thanks to a rated capacity of 16.7 Ah and approx. 625 Wh energy content, the lithium-ion battery brings maximum ranges and altitudes within your grasp. Energy: 625 wh, Voltage: 36V, Weight of just approx. 3,5 Kg, Compatible with DualBattery
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 48cm | 52cm |
|---|---|---|---|
| Stack Reach Ratio | 1.354 mm | 1.335 mm | 1.324 mm |
| Stack | 616 mm | 621 mm | 629 mm |
| Reach | 455 mm | 465 mm | 475 mm |
| Top Tube Length | 599 mm | 611 mm | 623 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 86 mm | 97 mm | 106 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1236 mm | 1248 mm | 1262 mm |
| Wheels | 29" | 29" | 29" |
About this model
E-Power iLink 180 Factory 45 is a Corratec E E Power model. 97 e-bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro e-bikes average price
If you want an acceptable Enduro e-bike you should know that the average price is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
E-Power iLink 180 Factory 45 components
Fork
The E-Power iLink 180 Factory 45 comes factory-installed with the RockShox ZEB Ultimate fork. This has a travel range of 180mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Corratec E-Power iLink 180 Factory 45 e-bike has the Rockshox Super Deluxe Ultimate model installed, and has a travel of 180mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
As for the wheels, Corratec E-Power iLink 180 Factory 45 2022, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The E-Power iLink 180 Factory 45 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Dropper post
The Corratec model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
