Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 180mm -
Travel Rear 180mm -
Fork RockShox Yari RC
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery BOSCH PowerTube 625Wh , What more could you want? The new PowerTube 625 lets you enjoy long and mountainous rides, while still reserving plenty of energy for every adventure. Thanks to a rated capacity of 16.7 Ah and approx. 625 Wh energy content, the lithium-ion battery brings maximum ranges and altitudes within your grasp. Energy: 625 wh, Voltage: 36V, Weight of just approx. 3,5 Kg, Compatible with DualBattery -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec E-Power iLink 180 , Shadow Edge Tube 2.0 - worldwide most stable and safest corratec E-Bike frame. 3.345 gram: Frame weight including all components and paintwork. Full carbon fully including the rear body. 180mm iLink technology. Material: Carbon
Suspension Fork
Rockshox Yari RC 29" , Suspension travel: 180 mm
Rear Shock
Rockshox Super Deluxe
Drivetrain
Rear Derailleur
SRAM GX Eagle 12S
Shift Levers
SRAM NX Eagle Single Click
Cassette
SRAM PG1210 Eagle 12S , Number of pinions; Ratio: 12s; 10 12 14 16 18 21 24 28 32 36 42 50
Crank
SRAM X-Sync E-Power Crank , Number of chainrings; Ratio: 1s; 34
Wheels
Rims
ZZYZX Cross Attack 29 Boost front , Rim outer diameter: 29.00 zoll, Type of tires: clincher, ZZYZX Cross Attack 650B Boost rear , Rim outer diameter: 27.50 zoll, Type of tires: clincher
Tires
Michelin Wild Enduro TLR 29 front , Inside diameter: 29.00 zoll, Type of tires: clincher, Width: 2.4 inch, Michelin Wild Enduro TLR 650B rear , Inside diameter: 27.50 zoll, Type of tires: clincher, Width: 2.8 inch
Brakes
Brakes
SRAM Guide front , Size brake disc: 200 mm, SRAM Guide rear , Size brake disc: 203 mm
Cockpit
Stem
ZZYZX SL Alloy
Handlebar
ZZYZX SL Alloy Handlebar , Width: 800mm
Seat
Saddle
Selle Italia Model X
Seatpost
Kindshock 900i , Outer diameter: 31.6 mm
Motor & Battery
Motor
BOSCH Performance Line CX , No path too steep, no challenge too great: the Performance Line CX is made for anyone for whom the trail is a second home. eMTB mode will always give you the power you need at precisely the right moment. Max speed: 25 km/h, Power: 250 watt, Torque: 85 Nm (J), Max. support of 340% For powerful propulsion, an extremely sporty riding style and fast sprints. Weight of just approximately 2,9 Kg.
Battery
BOSCH PowerTube 625Wh , What more could you want? The new PowerTube 625 lets you enjoy long and mountainous rides, while still reserving plenty of energy for every adventure. Thanks to a rated capacity of 16.7 Ah and approx. 625 Wh energy content, the lithium-ion battery brings maximum ranges and altitudes within your grasp. Energy: 625 wh, Voltage: 36V, Weight of just approx. 3,5 Kg, Compatible with DualBattery
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 48cm | 52cm |
|---|---|---|---|
| Stack Reach Ratio | 1.354 mm | 1.335 mm | 1.324 mm |
| Stack | 616 mm | 621 mm | 629 mm |
| Reach | 455 mm | 465 mm | 475 mm |
| Top Tube Length | 599 mm | 611 mm | 623 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 86 mm | 97 mm | 106 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1236 mm | 1248 mm | 1262 mm |
| Wheels | 29" | 29" | 29" |
Model Overview
E-Power iLink 180 Race completes the Corratec E E Power model. There are 97 e-bikes that carry this model name. You can easily view all of the Corratec E E Power e-bikes models from 2022, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro e-bikes average price
According to our calculations, the average cost of an Enduro e-bike that is reliable is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
E-Power iLink 180 Race components
Fork
Corratec E-Power iLink 180 Race 2022 e-bike is equipped with the RockShox Yari RC fork, and has 180mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this e-bike has the Rockshox Super Deluxe model, with a travel of 180mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When it comes to wheels, the E-Power iLink 180 Race e-bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
