Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCR Air
-
Groupset SX Eagle -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery BOSCH PowerTube 750Wh , Energy: 750 wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec E-Power MTC 100 Wave , Material: Alloy
Suspension Fork
SR Suntour XCR32-BOOST-AIR LOR DS , Suspension travel: 100 mm
Rear Shock
SR Suntour Edge LOR
Drivetrain
Rear Derailleur
SRAM SX Eagle 12S
Shift Levers
SRAM SX Eagle
Cassette
SRAM CS PG1230 11-50T , Number of pinions; Ratio: 12s; 11 13 15 17 19 22 25 28 32 36 42 50
Crank
ZZYZX E-Power Crank , Number of chainrings; Ratio: 1s; 38
Wheels
Rims
ZZYZX MTC Cross front , Rim outer diameter: 27.50 zoll, ZZYZX MTC Cross rear , Rim outer diameter: 27.50 zoll
Tires
Schwalbe Johnny Watts front , Inside diameter: 27.50 zoll, Schwalbe Johnny Watts rear , Inside diameter: 27.50 zoll
Brakes
Brakes
Tektro HD-M275 PM FL950 front , Size brake disc: 180 mm, Tektro HD-M275 RR2000 rear , Size brake disc: 180 mm
Cockpit
Stem
Corratec ICR System
Handlebar
ZZYZX SL Alloy Handlebar , Width: 760mm
Seat
Saddle
ZZYZX Sport Saddle
Seatpost
Kindshock 900i , Outer diameter: 31.6 mm
Motor & Battery
Motor
BOSCH Performance Line CX , Max speed: 25 km/h, Power: 250 watt, Torque: 85 Nm (J)
Battery
BOSCH PowerTube 750Wh , Energy: 750 wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.427 mm | 1.454 mm | 1.464 mm |
| Stack | 612 mm | 631 mm | 650 |
| Reach | 429 mm | 434 mm | 444 mm |
| Top Tube Length | 605 mm | 615 mm | 630 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 485 mm | 485 mm | 485 mm |
| Wheelbase | 1182 mm | 1194 mm | 1211 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
E-Power MTC 100 Wave completes the Corratec E E Power model. Corratec released 97 e-bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry e-bikes
If you want an acceptable Crosscountry e-bike you should know that the average price is 2453$. However, you could also get a good Crosscountry e-bike even if you pay a lower amount than the average price. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
Corratec E-Power MTC 100 Wave 2023 e-bike is equipped with the Suntour XCR Air fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
As for the wheels, Corratec E-Power MTC 100 Wave 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The E-Power MTC 100 Wave comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
The Corratec model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
