Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Fork RockShox 35 Silver
-
Groupset GX Eagle, SRAM -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery BOSCH PowerTube 750Wh , Energy: 750 wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec E-Power MTC 120 , Material: Alloy
Suspension Fork
SRAM Rockshox 35 Silver TK29" , Suspension travel: 130 mm
Rear Shock
SRAM Rockshox Deluxe Select
Drivetrain
Rear Derailleur
SRAM GX Eagle Lunar 12S
Shift Levers
SRAM GX Eagle
Cassette
SRAM PG1210 Eagle 11-50T , Number of pinions; Ratio: 12s; 11 13 15 17 19 22 25 28 32 36 42 50
Crank
SRAM X-SYNC 2 34T , Number of chainrings; Ratio: 1s; 34
Wheels
Rims
ZZYZX 29" front , Number of spokes: 32, ZZYZX 29" rear , Number of spokes: 32
Tires
Schwalbe Johnny Watts front , Inside diameter: 29.00 zoll, Schwalbe Johnny Watts rear , Inside diameter: 29.00 zoll
Brakes
Brakes
SRAM Guide T front , Size brake disc: 203 mm, SRAM Guide T rear , Size brake disc: 203 mm
Cockpit
Stem
ZZYZX SL Alloy Stem
Handlebar
ZZYZX Alloy Handlebar
Seat
Saddle
Selle Royal Essenza Moderate
Seatpost
Kindshock RAGEi Suspension 30.9mm , Outer diameter: 30.9 mm
Motor & Battery
Motor
BOSCH Performance Line CX , Max speed: 25 km/h, Power: 250 watt, Torque: 85 Nm (J)
Battery
BOSCH PowerTube 750Wh , Energy: 750 wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 39cm | 44cm | 49cm | 54cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.484 mm | 1.418 mm | 1.366 mm | 1.329 mm |
| Stack | 638 mm | 638 mm | 642 mm | 651 mm |
| Reach | 430 mm | 450 mm | 470 mm | 490 mm |
| Top Tube Length | 613 mm | 633 mm | 654 mm | 677 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 155 mm | 155 mm | 160 mm | 170 mm |
| Chainstay Length | 468 mm | 468 mm | 468 mm | 468 mm |
| Wheelbase | 1212 mm | 1232 mm | 1254 mm | 1278 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
E-Power MTC 120 Pro is a Corratec E E Power model. Corratec launched 148 e-bikes of this model so far. Take a sneak peek at all Corratec E E Power e-bikes models from 2024, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail e-bikes average price
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
This e-bike has the RockShox 35 Silver fork installed. The fork’s travel is 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When leaving the production line, the E-Power MTC 120 Pro model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Corratec E-Power MTC 120 Pro is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
