corratec E-Power Trekking 28 SE 3.0 CX7 12S Wave 2023
2023 E-bike
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Fork Suntour NEX -
Groupset SX Eagle -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery BOSCH PowerTube 750Wh , Energy: 750 wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec E-Power Trekking 28 SE 3.0 CX7 12S Wave , Material: Alloy
Suspension Fork
SR Suntour NEX E25 DS 700C
Drivetrain
Rear Derailleur
SRAM SX Eagle
Shift Levers
SRAM SX Eagle Single Click E Trigger
Cassette
SRAM CS PG1210 11-50T
Crank
SRAM PG1210 Eagle , Number of chainrings; Ratio: 1s; 38
Wheels
Rims
Corratec Sport HD , Rim outer diameter: 29.00 zoll
Tires
Schwalbe Land Cruiser
Brakes
Brakes
Shimano Disc Brake MT200 , Size brake disc: 180 mm front, Size brake disc: 160 mm rear
Cockpit
Stem
ZZYZX SL Alloy Stem
Handlebar
ZZYZX Trekking Handlebar
Seat
Saddle
Selle Royal Ariel Ladies
Seatpost
ZZYZX Suspension Seatpost , Outer diameter: 30.9 mm
Motor & Battery
Motor
BOSCH Performance Line CX , Max speed: 25 km/h, Power: 250 watt, Torque: 85 Nm (J)
Battery
BOSCH PowerTube 750Wh , Energy: 750 wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 50cm | 55cm |
|---|---|---|---|
| Stack Reach Ratio | 1.624 mm | 1.629 mm | 1.631 mm |
| Stack | 666 mm | 676 mm | 685 mm |
| Reach | 410 mm | 415 mm | 420 mm |
| Top Tube Length | 601 mm | 608 mm | 616 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 180 mm | 190 mm | 200 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1159 mm | 1168 mm | 1176 mm |
| Wheels | 29" | 29" | 29" |
Model Overview
E-Power Trekking 28 SE 3.0 CX7 12S Wave is part of the Corratec E E Power model. Corratec released 97 e-bikes variations of this model so far. You can easily view all of the Corratec E E Power e-bikes models from 2023, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Commuter e-bikes average price
According to our math, the average price for a trustworthy Commuter e-bike is 2569$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Commuter e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
The fork installed on this bike is the Suntour NEX model. The travel on this model is mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
As for the wheels, Corratec E-Power Trekking 28 SE 3.0 CX7 12S Wave 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
