Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 63mm -
Fork Suntour NEX
-
Suspension Hardtail -
Motor Bosch 250W 50Nm mid-drive -
Battery BOSCH PowerPack 545 Performance , Energy: 545 wh, Outstanding battery efficiency, Easy to store and quick to recharge, Ergonomic handling, Long service life -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec E-Power Urban 28 Fusion Tube Wave , Material: Alloy
Suspension Fork
SR Suntour NEX-DS 700C , Suspension travel: 63 mm
Drivetrain
Rear Derailleur
L-Twoo A11-X 11S
Shift Levers
L-Twoo AX 11S
Cassette
L-Twoo CS A11 , Number of pinions; Ratio: 11s; 11 13 15 17 19 21 24 28 32 37 46
Crank
ZZYZX E-Power Crank , Number of chainrings; Ratio: 1s; 38
Wheels
Rims
ZZYZX MTC Cross , Rim outer diameter: 29.00 zoll
Tires
Schwalbe Energizer Plus Performance
Brakes
Brakes
Shimano Disc Brake MT200 front , Size brake disc: 180 mm, Shimano Disc Brake MT200 rear , Size brake disc: 160 mm
Cockpit
Stem
ZZYZX SL Alloy Stem
Handlebar
ZZYZX Trekking Handlebar
Seat
Saddle
Selle Royal Orbis
Seatpost
ZZYZX Suspension Seatpost , Outer diameter: 30.9 mm
Motor & Battery
Motor
BOSCH Active Line Plus , Harmoniously balanced or assertively powerful? Natural is what's important. The Bosch riding sensation creates a unique eBike experience. Three sensors measure pedaling power, cadence, and speed more than 1000 times per second. This enables the rider and the eBike to interact with each other organically. Just the right level of support with every push of the pedal – for relaxed bike tours and more power for everyday use. Ideal for leisure eBike enthusiasts, Drive Unit Active Cruise provides support at speeds up to 25 km/h and optimally balanced power. Max speed: 25 km/h, Power: 250 watt, Torque: 50 Nm (J), Compact and lightweight, Exceptional design
Battery
BOSCH PowerPack 545 Performance , Energy: 545 wh, Outstanding battery efficiency, Easy to store and quick to recharge, Ergonomic handling, Long service life
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 50cm | 55cm |
|---|---|---|---|
| Stack Reach Ratio | 1.745 mm | 1.754 mm | 1.763 mm |
| Stack | 672 mm | 686 mm | 700 |
| Reach | 385 mm | 391 mm | 397 mm |
| Top Tube Length | 590 mm | 600 mm | 610 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 180 mm | 195 mm | 210 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1149 mm | 1160 mm | 1172 mm |
| Wheels | 29" | 29" | 29" |
Model Overview
E-Power Urban 28 AP5 11S Wave is a Corratec E E Power model. Corratec launched 97 e-bikes of this model so far. Take a sneak peek at all Corratec E E Power e-bikes models from 2023, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Commuter e-bikes
If you want an acceptable Commuter e-bike you should know that the average price is 2569$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Commuter e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
E-Power Urban 28 AP5 11S Wave components
Fork
The E-Power Urban 28 AP5 11S Wave comes factory-installed with the Suntour NEX fork. This has a travel range of 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When leaving the production line, the E-Power Urban 28 AP5 11S Wave model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Corratec E-Power Urban 28 AP5 11S Wave is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
