Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Nexus, SRAM -
Suspension Hardtail -
Motor Bosch 250W 50Nm mid-drive -
Battery BOSCH PowerPack 500 Performance , PowerPack 500, 400 and 300 are, with optimum range, the perfect choice for eMountain bikers, sporty riders and commuters. The lithium-ion battery has the highest energy density, smallest dimensions and lowest weight on the market. By coupling two PowerPacks, the DualBattery system gives you double range. Energy: 500 wh, Outstanding battery efficiency, Easy to store and quick to recharge, Ergonomic handling, Long service life -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec E-Power Urban 28 Wave
Suspension Fork
SR Suntour NEX-DS 700C , Suspension travel: 63 mm
Drivetrain
Shift Levers
Shimano NEXUS Revo Shifter
Cassette
Shimano Nexus , Number of pinions; Ratio: 8s; 19
Crank
SRAM X-SYNC , Number of chainrings; Ratio: 1s; 38
Wheels
Rims
ZZYZX Trekking 29er Disc front , Rim outer diameter: 29.00 zoll, Type of tires: clincher, ZZYZX Trekking 29er Disc rear , Rim outer diameter: 29.00 zoll, Type of tires: clincher
Tires
Schwalbe Energizer Active Plus front , Inside diameter: 28.00 zoll, Width: 50 mm, Type of tires: clincher, Schwalbe Energizer Active Plus rear , Inside diameter: 28.00 zoll, Width: 50 mm, Type of tires: clincher
Brakes
Brakes
Shimano MT 200 front , Size brake disc: 180 mm, Shimano MT200 rear , Size brake disc: 160 mm
Cockpit
Stem
ZZYZX SL Alloy Stem
Handlebar
ZZYZX Trekking Handlebar
Seat
Saddle
Selle Royal Milo Plus Trekking
Seatpost
ZZYZX Alloy Seatpost
Motor & Battery
Motor
BOSCH Active Line Plus , Harmoniously balanced or assertively powerful? Natural is what's important. The Bosch riding sensation creates a unique eBike experience. Three sensors measure pedaling power, cadence, and speed more than 1000 times per second. This enables the rider and the eBike to interact with each other organically. Just the right level of support with every push of the pedal – for relaxed bike tours and more power for everyday use. Ideal for leisure eBike enthusiasts, Drive Unit Active Cruise provides support at speeds up to 25 km/h and optimally balanced power. Max speed: 25 km/h, Power: 250 watt, Torque: 50 Nm (J), Compact and lightweight, Exceptional design
Battery
BOSCH PowerPack 500 Performance , PowerPack 500, 400 and 300 are, with optimum range, the perfect choice for eMountain bikers, sporty riders and commuters. The lithium-ion battery has the highest energy density, smallest dimensions and lowest weight on the market. By coupling two PowerPacks, the DualBattery system gives you double range. Energy: 500 wh, Outstanding battery efficiency, Easy to store and quick to recharge, Ergonomic handling, Long service life
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 50cm | 55cm |
|---|---|---|---|
| Stack Reach Ratio | 1.745 mm | 1.754 mm | 1.763 mm |
| Stack | 672 mm | 686 mm | 700 |
| Reach | 385 mm | 391 mm | 397 mm |
| Top Tube Length | 590 mm | 600 mm | 610 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 180 mm | 195 mm | 210 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1149 mm | 1160 mm | 1172 mm |
| Wheels | 29" | 29" | 29" |
Model Overview
E-Power Urban 28 AP5 8S Wave completes the Corratec E E Power model. 97 e-bikes variations carry this model name so far. You can easily view all of the Corratec E E Power e-bikes models from 2022, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Commuter e-bikes
If you want to purchase a solid Commuter e-bike, it is important to know that the average cost is 2569$. However, this doesn’t mean that if you spend less money on a Commuter e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
The E-Power Urban 28 AP5 8S Wave comes factory-installed with the Suntour NEX fork. This has a travel range of 63mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the E-Power Urban 28 AP5 8S Wave e-bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Corratec E-Power Urban 28 AP5 8S Wave is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
