Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork Suntour XCR Air
-
Groupset Deore -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery BOSCH PowerTube 625Wh , Energy: 625 wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec E-Power X Vert Elite Trapez , Material: Alloy
Suspension Fork
SR Suntour XCR32-BOOST-AIR LOR , Suspension travel: 120 mm
Drivetrain
Rear Derailleur
Shimano Deore SGS
Shift Levers
Shimano Deore 11-Speed
Cassette
Shimano Deore , Number of pinions; Ratio: 11s; 11 13 15 17 19 21 24 28 32 37 42
Crank
ZZYZX E-Power Crank , Number of chainrings; Ratio: 1s; 34
Wheels
Rims
ZZYZX X Vert front , Rim outer diameter: 29.00 zoll, ZZYZX X Vert rear , Rim outer diameter: 27.50 zoll
Tires
Schwalbe Smart Sam 29" front , Inside diameter: 29.00 zoll, Schwalbe Smart Sam 650B rear , Inside diameter: 27.50 zoll, Type of tires: clincher
Brakes
Brakes
Shimano MT401 front , Size brake disc: 180 mm, Shimano MT410 rear , Size brake disc: 180 mm
Cockpit
Stem
ZZYZX SL Alloy Stem
Handlebar
ZZYZX SL Alloy Handlebar , Width: 760mm
Seat
Saddle
Selle Italia Italia Superflow Carbon
Seatpost
ZZYZX SL Alloy Seatpost , Outer diameter: 30.9 mm
Motor & Battery
Motor
BOSCH Performance Line CX , Max speed: 25 km/h, Power: 250 watt, Torque: 85 Nm (J)
Battery
BOSCH PowerTube 625Wh , Energy: 625 wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 39cm | 44cm | 49cm | 54cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.649 mm | 1.591 mm | 1.557 mm | 1.525 mm |
| Stack | 676 mm | 676 mm | 685 mm | 694 mm |
| Reach | 410 mm | 425 mm | 440 mm | 455 mm |
| Top Tube Length | 616 mm | 631 mm | 649 mm | 667 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 150 mm | 160 mm | 160 mm | 170 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1194 mm | 1209 mm | 1228 mm | 1247 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
E-Power X Vert Elite Trapez is a Corratec E E Power model. Corratec launched 97 e-bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail e-bikes average price
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Overview of components
Fork
Corratec E-Power X Vert Elite Trapez 2023 e-bike is equipped with the Suntour XCR Air fork, and has 120mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When leaving the production line, the E-Power X Vert Elite Trapez model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
