Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Fork RockShox Revelation RC
-
Groupset GX Eagle, SRAM -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery BOSCH PowerTube 750Wh , Energy: 750 wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec E-Power X Vert Gent
Suspension Fork
Rockshox FS Revelation 29" Boost , Suspension travel: 140 mm
Drivetrain
Rear Derailleur
SRAM GX Eagle 12S
Shift Levers
SRAM GX Eagle Single Click Trigger
Cassette
SRAM PG1210 Eagle 12S , Number of pinions; Ratio: 12s; 10 12 14 16 18 21 24 28 32 36 42 50
Crank
SRAM X-Sync E-Power Crank , Number of chainrings; Ratio: 1s; 34
Wheels
Rims
ZZYZX Cross Attack 29 Boost front , Rim outer diameter: 29.00 zoll, Type of tires: clincher, ZZYZX Cross Attack 650B Boost rear , Rim outer diameter: 27.50 zoll, Type of tires: clincher
Tires
Schwalbe Nobby Nic 29" front , Inside diameter: 29.00 zoll, Width: 60 mm, Schwalbe Nobby Nic 650B rear , Inside diameter: 27.50 zoll, Width: 70 mm
Brakes
Brakes
Magura MT Thirty front , Size brake disc: 203 mm, Magura MT Thirty rear , Size brake disc: 180 mm
Cockpit
Stem
ZZYZX SL Alloy
Handlebar
ZZYZX SL Alloy Handlebar , Width: 760mm
Seat
Saddle
Selle Italia Model X
Seatpost
Kindshock 860i , Outer diameter: 30.9 mm
Motor & Battery
Motor
BOSCH Performance Line CX , Max speed: 25 km/h, Power: 250 watt, Torque: 85 Nm (J)
Battery
BOSCH PowerTube 750Wh , Energy: 750 wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 44cm | 49cm | 54cm | 57cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.563 mm | 1.51 mm | 1.472 mm | 1.444 mm |
| Stack | 672 mm | 672 mm | 677 mm | 686 mm |
| Reach | 430 mm | 445 mm | 460 mm | 475 mm |
| Top Tube Length | 635 mm | 650 | 667 mm | 685 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 145 mm | 145 mm | 150 mm | 160 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1212 mm | 1227 mm | 1244 mm | 1263 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
E-Power X Vert Factory belongs to the Corratec E E Power model. Corratec released 97 e-bikes variations of this model so far. You can easily view all of the Corratec E E Power e-bikes models from 2022, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail e-bikes
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
E-Power X Vert Factory components
Fork
Corratec E-Power X Vert Factory 2022 e-bike is equipped with the RockShox Revelation RC fork, and has 140mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When it comes to wheels, the E-Power X Vert Factory e-bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Corratec E-Power X Vert Factory has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Dropper post
Every bike should have a dropper post, and this one does. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
