Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork Suntour XCR Air
-
Groupset SLX, Deore -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery BOSCH PowerTube 750Wh , Energy: 750 wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec E-Power X-Vert Pro Trapez , Material: Alloy
Suspension Fork
SR Suntour XCR32-Boost-AIR LOR DS 29" 120mm , Suspension travel: 120 mm
Drivetrain
Rear Derailleur
Shimano SLX 11s
Shift Levers
Shimano Deore 11S
Cassette
Shimano SLX 11s , Number of pinions; Ratio: 11s; 11 13 15 17 19 21 24 28 32 37 46
Crank
ZZYZX E-Power Crank , Number of chainrings; Ratio: 1s; 34
Wheels
Rims
ZZYZX 29" front , Number of spokes: 32, ZZYZX 650B rear , Number of spokes: 32
Tires
Schwalbe Smart Sam 29" front , Inside diameter: 29.00 zoll, Schwalbe Smart Sam 650B rear , Inside diameter: 27.50 zoll, Type of tires: clincher
Brakes
Brakes
Shimano MT420 4 piston front , Size brake disc: 180 mm, Shimano MT410 2 piston rear , Size brake disc: 180 mm
Cockpit
Stem
ZZYZX SL Alloy Stem
Handlebar
ZZYZX Alloy Handlebar
Seat
Saddle
Corratec Sport
Seatpost
ZZYZX SL Alloy Seatpost , Outer diameter: 30.9 mm
Motor & Battery
Motor
BOSCH Performance Line CX , Max speed: 25 km/h, Power: 250 watt, Torque: 85 Nm (J)
Battery
BOSCH PowerTube 750Wh , Energy: 750 wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 39cm | 44cm | 49cm | 54cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.649 mm | 1.591 mm | 1.557 mm | 1.525 mm |
| Stack | 676 mm | 676 mm | 685 mm | 694 mm |
| Reach | 410 mm | 425 mm | 440 mm | 455 mm |
| Top Tube Length | 616 mm | 631 mm | 649 mm | 667 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 150 mm | 160 mm | 160 mm | 170 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1194 mm | 1209 mm | 1228 mm | 1247 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
E-Power X Vert Pro Sport is part of the Corratec E E Power model. Corratec launched 148 e-bikes of this model so far. You can get a glimpse at all models from 2024, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail e-bikes average price
According to our calculations, the average cost of a Trail e-bike that is reliable is 3365$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
E-Power X Vert Pro Sport components
Fork
The E-Power X Vert Pro Sport comes factory-installed with the Suntour XCR Air fork. This has a travel range of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When leaving the production line, the E-Power X Vert Pro Sport model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The E-Power X Vert Pro Sport comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
