Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork Suntour RAIDON
-
Groupset XT, SLX -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery BOSCH PowerTube 750Wh , Energy: 750 wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec X Vert Pro Team , Material: Alloy
Suspension Fork
SR Suntour RAIDON34X-Boost EQ 2CR 29" 120 , Suspension travel: 120 mm
Drivetrain
Rear Derailleur
Shimano DEORE XT SGS 12S
Shift Levers
Shimano DEORE SLX SGS 12S
Cassette
Shimano SLX 12S , Number of pinions; Ratio: 12s; 10 12 14 16 18 21 24 28 33 39 45 51
Crank
ZZYZX E-Power Crank , Number of chainrings; Ratio: 1s; 34
Wheels
Rims
ZZYZX 29" front , Number of spokes: 32, ZZYZX 650B rear , Number of spokes: 32
Tires
Schwalbe Nobby Nic 29" front , Inside diameter: 29.00 zoll, Width: 60 mm, Schwalbe Nobby Nic 650B rear , Inside diameter: 27.50 zoll, Width: 70 mm
Brakes
Brakes
Shimano MT420 4 piston front , Size brake disc: 180 mm, Shimano MT410 2 piston rear , Size brake disc: 180 mm
Cockpit
Stem
ZZYZX SL Alloy Stem
Handlebar
ZZYZX Mountain Handlebar
Seat
Saddle
Selle Italia X3 XP BOOST Superflow
Seatpost
Kindshock RAGEi Suspension 30.9mm , Outer diameter: 30.9 mm
Motor & Battery
Motor
BOSCH Performance Line CX , Max speed: 25 km/h, Power: 250 watt, Torque: 85 Nm (J)
Battery
BOSCH PowerTube 750Wh , Energy: 750 wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 39cm | 44cm | 49cm | 54cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.509 mm | 1.456 mm | 1.398 mm | 1.354 mm |
| Stack | 611 mm | 619 mm | 629 mm | 639 mm |
| Reach | 405 mm | 425 mm | 450 mm | 472 mm |
| Top Tube Length | 574 mm | 596 mm | 624 mm | 649 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 91 mm | 99 mm | 110 mm | 121 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1119 mm | 1142 mm | 1171 mm | 1197 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
E-Power X Vert Pro Team is a Corratec E E Power model. There are 148 e-bikes that carry this model name. You can easily view all of the Corratec E E Power e-bikes models from 2024, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail e-bikes average price
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, this doesn’t mean that if you spend less money on a Trail e-bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
The fork installed on this bike is the Suntour RAIDON model. The travel on this model is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The wheels on E-Power X Vert Pro Team are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The E-Power X Vert Pro Team has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
