Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork RockShox Recon Silver RL
-
Groupset XT, SLX -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery BOSCH PowerTube 625Wh , What more could you want? The new PowerTube 625 lets you enjoy long and mountainous rides, while still reserving plenty of energy for every adventure. Thanks to a rated capacity of 16.7 Ah and approx. 625 Wh energy content, the lithium-ion battery brings maximum ranges and altitudes within your grasp. Energy: 625 wh, Voltage: 36V, Weight of just approx. 3,5 Kg, Compatible with DualBattery -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec E-Power X Vert Boost
Suspension Fork
Rockshox RS Recon 29" , Suspension travel: 120 mm
Drivetrain
Rear Derailleur
Shimano DEORE XT 12S
Shift Levers
Shimano DEORE SLX
Cassette
Shimano DEORE SLX 12S , Number of pinions; Ratio: 12s; 10 12 14 16 18 21 24 28 33 39 45 51
Crank
ZZYZX E-Power Crank , Number of chainrings; Ratio: 1s; 34
Wheels
Rims
ZZYZX Cross Attack 29 Boost front , Rim outer diameter: 29.00 zoll, Type of tires: clincher, ZZYZX Cross Attack 650B Boost rear , Rim outer diameter: 27.50 zoll, Type of tires: clincher
Tires
Schwalbe Nobby Nic 29" front , Inside diameter: 29.00 zoll, Width: 60 mm, Schwalbe Nobby Nic 650B rear , Inside diameter: 27.50 zoll, Width: 70 mm
Brakes
Brakes
Shimano Disc Brake MT420 front , Size brake disc: 180 mm, Shimano MT410 rear , Size brake disc: 180 mm
Cockpit
Stem
ZZYZX SL Alloy
Handlebar
ZZYZX SL Alloy Handlebar , Width: 760mm
Seat
Saddle
Selle Italia Model X
Seatpost
Kindshock 860i , Outer diameter: 30.9 mm
Motor & Battery
Motor
BOSCH Performance Line CX , No path too steep, no challenge too great: the Performance Line CX is made for anyone for whom the trail is a second home. eMTB mode will always give you the power you need at precisely the right moment. Max speed: 25 km/h, Power: 250 watt, Torque: 85 Nm (J), Max. support of 340% For powerful propulsion, an extremely sporty riding style and fast sprints. Weight of just approximately 2,9 Kg.
Battery
BOSCH PowerTube 625Wh , What more could you want? The new PowerTube 625 lets you enjoy long and mountainous rides, while still reserving plenty of energy for every adventure. Thanks to a rated capacity of 16.7 Ah and approx. 625 Wh energy content, the lithium-ion battery brings maximum ranges and altitudes within your grasp. Energy: 625 wh, Voltage: 36V, Weight of just approx. 3,5 Kg, Compatible with DualBattery
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 44cm | 49cm | 54cm | 57cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.563 mm | 1.51 mm | 1.472 mm | 1.444 mm |
| Stack | 672 mm | 672 mm | 677 mm | 686 mm |
| Reach | 430 mm | 445 mm | 460 mm | 475 mm |
| Top Tube Length | 635 mm | 650 | 667 mm | 685 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 145 mm | 145 mm | 150 mm | 160 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1212 mm | 1227 mm | 1244 mm | 1263 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
E-Power X Vert Pro Team SE belongs to the Corratec E E Power model. Corratec released 97 e-bikes variations of this model so far. Take a sneak peek at all Corratec E E Power e-bikes models from 2022, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail e-bikes
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, this doesn’t mean that if you spend less money on a Trail e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
E-Power X Vert Pro Team SE components
Fork
Corratec E-Power X Vert Pro Team SE 2022 e-bike is equipped with the RockShox Recon Silver RL fork, and has 120mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
As for the wheels, Corratec E-Power X Vert Pro Team SE 2022, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Corratec E-Power X Vert Pro Team SE is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Dropper post
Corratec E-Power X Vert Pro Team SE includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
