Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 80mm -
Fork Suntour XCM
-
Groupset Alivio, Acera -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec MTC Trapez
Suspension Fork
SR Suntour XCM , Suspension travel: 80 mm
Drivetrain
Rear Derailleur
Shimano Alivio 9S
Front Derailleur
Shimano Acera
Shift Levers
Shimano ALTUS
Cassette
Shimano ALTUS , Number of pinions; Ratio: 9s; 11 13 15 17 20 23 26 30 36
Crank
Shimano MT210 , Number of chainrings; Ratio: 2s; 46/30
Wheels
Rims
ZZYZX 29er Disc
Tires
Schwalbe Smart Sam 29" , Inside diameter: 29.00 zoll, Width: 57 mm
Brakes
Brakes
Clarks M2 , Size brake disc: 180 mm front, Size brake disc: 160 mm rear
Cockpit
Stem
ZZYZX SL Alloy Stem
Handlebar
ZZYZX SL Alloy Handlebar
Seat
Saddle
ZZYZX Sport Saddle
Seatpost
ZZYZX SL Alloy Seatpost , Outer diameter: 30.9 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 39cm | 44cm | 49cm | 54cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.727 mm | 1.699 mm | 1.635 mm | 1.556 mm |
| Stack | 644 mm | 649 mm | 649 mm | 649 mm |
| Reach | 373 mm | 382 mm | 397 mm | 417 mm |
| Top Tube Length | 570 mm | 580 mm | 595 mm | 615 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 155 mm | 160 mm | 160 mm | 160 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1105 mm | 1116 mm | 1131 mm | 1151 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
MTC Expert Trapez completes the Corratec Mtc model. 12 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Commuter bikes
According to our math, the average price for a trustworthy Commuter bike is 762$. However, this doesn’t mean that if you spend less money on a Commuter bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
MTC Expert Trapez components
Fork
This bike has the Suntour XCM fork installed. The fork’s travel is 80mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
As for the wheels, Corratec MTC Expert Trapez 2023, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The MTC Expert Trapez comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
