Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Manitou Markhor
-
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec Revo Bow , Superlight Frame. Maximum propulsion: Extremely stiff head tube and bottom bracket for maximum propulsion and control. Bow frame: New frame shape with excellent Flexibility and cushioning. Race geometry. Material: Carbon
Suspension Fork
Manitou Markhor 29" , Suspension travel: 100 mm
Drivetrain
Rear Derailleur
SRAM SX Eagle
Shift Levers
SRAM SX Eagle
Cassette
SRAM PG1210 Eagle 11-50T , Number of pinions; Ratio: 12s; 11 13 15 17 19 22 25 28 32 36 42 50
Crank
SRAM SX EAGLE DUB , Number of chainrings; Ratio: 1s; 32
Wheels
Rims
ZZYZX Cross-R 29" front , ZZYZX Cross-R 29" rear
Tires
Schwalbe Nobby Nic front , Inside diameter: 29.00 zoll, Schwalbe Nobby Nic rear , Inside diameter: 29.00 zoll
Brakes
Brakes
SRAM Level T front , Size brake disc: 180 mm, SRAM Level T rear , Size brake disc: 160 mm
Cockpit
Stem
ZZYZX SL Alloy Stem
Handlebar
ZZYZX Mountain Handlebar
Seat
Saddle
Selle Italia Model X
Seatpost
ZZYZX SL Alloy Seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 39cm | 44cm | 49cm | 54cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.486 mm | 1.432 mm | 1.384 mm | 1.343 mm |
| Stack | 605 mm | 610 mm | 620 mm | 630 mm |
| Reach | 407 mm | 426 mm | 448 mm | 469 mm |
| Top Tube Length | 580 mm | 600 mm | 625 mm | 650 |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 121 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1085 mm | 1106 mm | 1132 mm | 1158 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
Revo BOW belongs to the Corratec Revo model. There are 15 bikes that carry this model name. You can easily view all of the Corratec Revo bikes models from 2024, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Revo BOW components
Fork
Corratec Revo BOW 2024 bike is equipped with the Manitou Markhor fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The wheels on Revo BOW are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
