Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox SID SL Select
-
Groupset GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec Revo Bow , Superlight Frame. Maximum propulsion: Extremely stiff head tube and bottom bracket for maximum propulsion and control. Bow frame: New frame shape with excellent Flexibility and cushioning. Race geometry. Material: Carbon
Suspension Fork
Rockshox SID SL Select 29" Boost , Suspension travel: 100 mm
Drivetrain
Rear Derailleur
SRAM GX Eagle 12S
Shift Levers
SRAM GX Eagle
Cassette
SRAM PG1230 Eagle , Number of pinions; Ratio: 12s; 11 13 15 17 19 22 25 28 32 36 42 50
Crank
SRAM GX Eagle DUB , Number of chainrings; Ratio: 1s; 32
Wheels
Rims
Mavic Crossmax 29"
Tires
Schwalbe Nobby Nic , Inside diameter: 29.00 zoll
Brakes
Brakes
SRAM Level T , Size brake disc: 180 mm front, Size brake disc: 160 mm rear
Cockpit
Stem
ZZYZX SL Alloy Stem , ICR: Internal Cable Routing.
Handlebar
ZZYZX SL Alloy Handlebar , Width: 760mm
Seat
Saddle
Selle Italia Model X
Seatpost
ZZYZX SL Alloy Seatpost , Outer diameter: 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 39cm | 44cm | 49cm | 54cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.486 mm | 1.432 mm | 1.384 mm | 1.343 mm |
| Stack | 605 mm | 610 mm | 620 mm | 630 mm |
| Reach | 407 mm | 426 mm | 448 mm | 469 mm |
| Top Tube Length | 580 mm | 600 mm | 625 mm | 650 |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 121 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1085 mm | 1106 mm | 1132 mm | 1158 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
Revo BOW Elite belongs to the Corratec Revo model. Corratec released 10 bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
The Revo BOW Elite comes factory-installed with the RockShox SID SL Select fork. This has a travel range of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When it comes to wheels, the Revo BOW Elite bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Corratec Revo BOW Elite is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
