Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox SID SL Ultimate
-
Groupset XX1 Eagle AXS, X01 Eagle AXS -
Suspension Hardtail -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec Revo BOW SL , High End Carbon Frame. Superlight Frame. Maximum propulsion: Extremely stiff head tube and bottom bracket for maximum propulsion and control. Bow frame: New frame shape with excellent Flexibility and cushioning. Race geometry.
Suspension Fork
Rockshox SID SL Ultimate 29" Boost , Suspension travel: 100 mm
Drivetrain
Rear Derailleur
SRAM XX1 Eagle AXS 12S
Shift Levers
SRAM AXS Eagle
Cassette
SRAM XG1299 Eagle , Number of pinions; Ratio: 12S; 10 12 14 16 18 21 24 28 32 36 42 52
Crank
SRAM XX1 Eagle DUB , Number of chainrings; Ratio: 1s; 32
Wheels
Rims
DT Swiss XCR 1200 Spline front , Rim outer diameter: 29.00 zoll, DT Swiss XCR 1200 Spline rear , Rim outer diameter: 29.00 zoll
Tires
Schwalbe Racing Ray front , Inside diameter: 29.00 zoll, Schwalbe Racing Ralph rear , Inside diameter: 29.00 zoll
Brakes
Brakes
SRAM Level Ultimate front , Size brake disc: 180 mm, SRAM Level Ultimate rear , Size brake disc: 160 mm
Cockpit
Stem
ZZYZX SL Alloy Stem , ICR: Internal Cable Routing.
Handlebar
ZZYZX SLR Carbon , Material: Carbon
Seat
Saddle
Selle Italia Superflow Carbon
Seatpost
ZZYZX Carbon Seatpost , Outer diameter: 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 39cm | 44cm | 49cm | 54cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.486 mm | 1.432 mm | 1.384 mm | 1.343 mm |
| Stack | 605 mm | 610 mm | 620 mm | 630 mm |
| Reach | 407 mm | 426 mm | 448 mm | 469 mm |
| Top Tube Length | 580 mm | 600 mm | 625 mm | 650 |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 121 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1085 mm | 1106 mm | 1132 mm | 1158 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
Revo BOW SL Factory is a Corratec Revo model. Corratec launched 10 bikes of this model so far. You can easily view all of the Corratec Revo bikes models from 2022, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Revo BOW SL Factory components
Fork
The fork installed on this bike is the RockShox SID SL Ultimate model. The travel on this model is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The Revo BOW SL Factory 2022 bike is equipped with 29″ carbon wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
