Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox SID SL Select
-
Groupset XT, SLX -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec Revo BOW SL , High End Carbon Frame. Superlight Frame. Maximum propulsion: Extremely stiff head tube and bottom bracket for maximum propulsion and control. Bow frame: New frame shape with excellent Flexibility and cushioning. Race geometry.
Suspension Fork
Rockshox SID SL Select 29" Boost , Suspension travel: 100 mm
Drivetrain
Rear Derailleur
Shimano DEORE XT 12S
Shift Levers
Shimano SLX
Cassette
Shimano DEORE SLX 12S , Number of pinions; Ratio: 12s; 10 12 14 16 18 21 24 28 33 39 45 51
Crank
Shimano Deore SLX , Number of chainrings; Ratio: 1s; 32
Wheels
Rims
DT Swiss M 1900 Spline 29 front , Rim outer diameter: 29.00 zoll, Type of tires: clincher, DT Swiss M 1900 Spline 29 rear , Rim outer diameter: 29.00 zoll, Type of tires: clincher
Tires
Schwalbe Racing Ray front , Inside diameter: 29.00 zoll, Schwalbe Racing Ray rear , Inside diameter: 29.00 zoll
Brakes
Brakes
Shimano SLX front , Size brake disc: 180 mm, Shimano SLX rear , Size brake disc: 160 mm
Cockpit
Stem
ZZYZX SL Alloy Stem , ICR: Internal Cable Routing.
Handlebar
ZZYZX SLR Carbon , Material: Carbon
Seat
Saddle
Selle Italia Model X
Seatpost
ZZYZX Carbon Seatpost , Outer diameter: 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 39cm | 44cm | 49cm | 54cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.486 mm | 1.432 mm | 1.384 mm | 1.343 mm |
| Stack | 605 mm | 610 mm | 620 mm | 630 mm |
| Reach | 407 mm | 426 mm | 448 mm | 469 mm |
| Top Tube Length | 580 mm | 600 mm | 625 mm | 650 |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 121 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1085 mm | 1106 mm | 1132 mm | 1158 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
Revo BOW SL Pro is part of the Corratec Revo model. Corratec released 10 bikes variations of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
This bike has the RockShox SID SL Select fork installed. The fork’s travel is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When leaving the production line, the Revo BOW SL Pro model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Revo BOW SL Pro comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
