Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox SID SL Select
-
Groupset X01 Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec Revo BOW SL , High End Carbon Frame. Superlight Frame. Maximum propulsion: Extremely stiff head tube and bottom bracket for maximum propulsion and control. Bow frame: New frame shape with excellent Flexibility and cushioning. Race geometry.
Suspension Fork
Rockshox SID SL Select 29" Boost , Suspension travel: 100 mm
Drivetrain
Rear Derailleur
SRAM X01 Eagle
Shift Levers
SRAM X01 Eagle Trigger 12S
Cassette
SRAM XG1295 Eagle , Number of pinions; Ratio: 12S; 10 12 14 16 18 21 24 28 32 36 42 52
Crank
SRAM X01 Eagle DUB , Number of chainrings; Ratio: 1s; 32
Wheels
Rims
DT Swiss XMC1501 Spline Boost , Rim outer diameter: 29.00 zoll
Tires
Schwalbe Racing Ray front , Inside diameter: 29.00 zoll, Schwalbe Racing Ralph rear , Inside diameter: 29.00 zoll
Brakes
Brakes
SRAM G2 , Size brake disc: 180 mm front, Size brake disc: 160 mm rear
Cockpit
Stem
ZZYZX SL Alloy Stem , ICR: Internal Cable Routing.
Handlebar
ZZYZX SLR Carbon , Material: Carbon
Seat
Saddle
Selle Italia Superflow Manganese
Seatpost
ZZYZX Carbon Seatpost , Outer diameter: 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 39cm | 44cm | 49cm | 54cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.486 mm | 1.432 mm | 1.384 mm | 1.343 mm |
| Stack | 605 mm | 610 mm | 620 mm | 630 mm |
| Reach | 407 mm | 426 mm | 448 mm | 469 mm |
| Top Tube Length | 580 mm | 600 mm | 625 mm | 650 |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 121 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1085 mm | 1106 mm | 1132 mm | 1158 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
Revo BOW SL Pro Team is part of the Corratec Revo model. There are 10 bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
The RockShox SID SL Select is included from the factory. It has a travel distance of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The Revo BOW SL Pro Team 2023 bike is equipped with 29″ carbon wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Corratec Revo BOW SL Pro Team is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
